Car Wiring Diagrams for Charging circuit for Honda Element YH2 facelift (2006-2008)

ALTERNATOR C SIGNAL ALTERNATOR FR SIGNAL ALTERNATOR IG ALTERNATOR L SIGNAL BATTERY BLK WIRE BLU WIRE CHARGING IND CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER COMPUTER DATA LINES SYSTEM DRIVER CIRCUIT ECM/PCM (BEHIND GLOVE BOX) ELD UNIT ELD UNIT INPUT F-CAN TRANSCEIVER FUSE 10 FUSE 19 FUSE 4 GAUGE CONTROL MODULE GRN WIRE GRN/BLK WIRE HOT IN ON OR START JUNCTION CONNECTOR RED WIRE STARTING CIRCUIT TRANSMISSION UNDERDASH FUSE/ RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE
