Exterior lamps circuit for Honda Element YH2 facelift (2006-2008)

1 1 (W/ SC) (W/O SC) 2 1 (W/ SC) (W/O SC) 3 2 (W/O SC) (W/ SC) BLK WIRE BLK/RED WIRE BLU WIRE COMBINATION LIGHT SWITCH FUSE 19 FUSE 2 FUSE 5 GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HAZARD WARNING SWITCH HAZARD WARNING SWITCH LIGHT HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN ON OR START LEFT LEFT FRONT SIDE MARKER LIGHT LEFT FRONT TURN SIGNAL/ PARKING LIGHTS MULTIPLEX CONTROL UNIT OFF OFF ON OFF PARK HEAD RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT RIGHT FRONT SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL/ PARKING LIGHTS SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH) SMALL LT RLY- TAILLIGHT RELAY TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD RELAY UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT) WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE

10 9 8 7 6 5 4 3 2 1 R TURN LT +B TRAILER STOP SW SMALL LT L TURN/STOP BACK-UP BACK-UP LAMPS CIRCUIT BLK WIRE BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE FUSE 7 GAUGE CONTROL ASSEMBLY GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND L TURN LT SMALL R TURN/STOP HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES LAMPS CIRCUIT LEFT BACK-UP LIGHT LEFT BRAKE LIGHT/ TAILLIGHT LEFT REAR TURN SIGNAL LIGHT LEFT TAILLIGHT ASSEMBLY LEFT TURN SIGNAL INDICATOR LICENSE PLATE LIGHT RED WIRE RED/YEL WIRE RIGHT BACK-UP LIGHT RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT REAR TURN SIGNAL LIGHT RIGHT TAILLIGHT ASSEMBLY RIGHT TURN SIGNAL INDICATOR TRAILER CONNECTOR TRAILER LIGHTING CONNECTOR (OPTIONAL) (REAR OF CARGO AREA) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE
