Honda Element YH2 facelift (2006-2008) power driver's mirror door lock switch switch Wiring diagram
This page shows the only wiring diagram for the component.power driver's mirror door lock switch switch, which is found in the car Honda Element YH2 facelift (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power driver's mirror door lock switch switch (1 of 1)
A/T SHIFT LOCK
BLK WIRE
BLOWER POWER TRANSISTOR
CRUISE CONTROL MAIN SWITCH
DATA LINK CONNECTOR
DRIVER'S DOOR LOCK KNOB SWITCH
FRONT (CANADA) ACCESSORY DRL POWER CONTROL UNIT SOCKET
GAUGE CONTROL MODULE
HEATER CONTROL PANEL
KEYLESS RECEIVER UNIT
MES CONNECTOR
MULTIPLEX CONTROL UNIT
POWER DRIVER'S MIRROR DOOR LOCK SWITCH SWITCH
POWER WINDOW MASTER SWITCH
REAR ACCESSORY POWER SOCKET RELAY
S GND
SIDE OF DASH, RIGHT OF STEERING COLUMN)
SRS UNIT
SWITCH
TPMS CONTROL UNIT
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
VSA OFF SWITCH
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> POWER DRIVER'S MIRROR DOOR LOCK SWITCH SWITCH
