Honda Element YH2 facelift 2 (2008-2011) under-dash fuse/relay box (behind left side of dash, right of steering Wiring diagram

This page shows the only wiring diagram for the component.under-dash fuse/relay box (behind left side of dash, right of steering, which is found in the car Honda Element YH2 facelift 2 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram under-dash fuse/relay box (behind left side of dash, right of steering (1 of 1)

Wiring diagram under-dash fuse/relay box (behind left side of dash, right of steering for Honda Element YH2 facelift 2 (2008-2011)

Get access

BLK WIRE BLU/RED WIRE CABLE REEL (UNDER STEERING COLUMN COVER) COLUMN) CRUISE CONTROL COMBINATION SWITCH FUSE 7 HORN (BEHIND LEFT SIDE OF FRONT BUMPER) HORN RELAY HORN SW HORN SWITCH HOT AT ALL TIMES MULTIPLEX CONTROL UNIT ORG/ WIRE SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH) STEERING WHEEL) UNDER- HOOD FUSE/ RELAY BOX (LEFT REAR OF ENGINE COMPT) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING

Go to component: -> Horn circuit -> UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING
