Honda Element YH2 facelift 2 (2008-2011) tpms control drl control unit unit Wiring diagram

+B DAY +B RR DOOR LT FOG LOCK BLK WIRE BLOWER MOTOR RELAY BLU/ORG WIRE BLU/RED WIRE COMBINATION LIGHT SWITCH CONSOLE ACCESSORY POWER SOCKET DRL CONTROL UNIT EX, SC FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 3 OF 4) FROM UNDERHOOD FUSE/RELAY BOX (FUSE 6) (DIAGRAM 1 OF 4) FROM UNDERHOOD FUSE/RELAY BOX (FUSE 9) (DIAGRAM 1 OF 4) FRONT ACCESSORY POWER SOCKET FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 2 FUSE 3 FUSE 5 (NOT USED) FUSE 7 FUSE FUSE 15 GAUGE CONTROL MODULE GRN/WHT WIRE HEADLIGHT RELAY IGNITION COIL A/F SENSOR RELAY RELAY J/C LEFT HEADLIGHT LIGHTING RLY MULTIPLEX CONTROL UNIT MULTIPLEX DRL H/L CONTROL SW UNIT REAR ACCESSORY POWER SOCKET REAR ACCESSORY POWER SOCKET RELAY REAR WINDOW DEFOGGER RELAY RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RIGHT HEADLIGHT SECURITY CONTROL UNIT CONNECTOR (OPTION) STEREO AMPLIFIER TO FUSE 24 (DIAGRAM 4 OF 4) TO POWER WINDOW RELAY (DIAGRAM 4 OF 4) TPMS CONTROL DRL CONTROL UNIT UNIT UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL/WHT WIRE
