Honda Element YH2 facelift 2 (2008-2011) hatch rear latch window switch defogger Wiring diagram
This page shows the only wiring diagram for the component.hatch rear latch window switch defogger, which is found in the car Honda Element YH2 facelift 2 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hatch rear latch window switch defogger (1 of 1)
BLK WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
EX, SC
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FUEL PUMP
FUEL TANK UNIT
HATCH REAR LATCH WINDOW SWITCH DEFOGGER
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT REAR DOOR LOWER SWITCH
LEFT REAR DOOR UPPER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILGATE LATCH SWITCH
LEFT TAILLIGHT ASSEMBLY
ODS UNIT
REAR ACCESSORY POWER SOCKET
REAR HIGH WINDOW MOUNT WIPER BRAKE MOTOR LIGHT
REAR WINDOW WIPER INTERMITTENT CONTROL UNIT
RIGHT BACK-UP LIGHT
RIGHT REAR
RIGHT REAR DOOR LOWER SWITCH
RIGHT REAR DOOR UPPER SWITCH
RIGHT REAR LEFT SIDE BACK-UP MARKER LIGHT LIGHT
RIGHT TAILLIGHT ASSEMBLY RIGHT REAR SIDE MARKER LIGHT
RIGHT TURN BRAKE SIGNAL LIGHT/ LIGHT TAILLIGHT
WHT WIRE
XM RECEIVER
Go to component: -> Ground distribution circuit (4 of 4) -> HATCH REAR LATCH WINDOW SWITCH DEFOGGER
