Honda Element YH2 facelift 2 (2008-2011) front power passenger's window power master window switch switch Wiring diagram

This page shows the only wiring diagram for the component.front power passenger's window power master window switch switch, which is found in the car Honda Element YH2 facelift 2 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front power passenger's window power master window switch switch (1 of 1)

Wiring diagram front power passenger's window power master window switch switch for Honda Element YH2 facelift 2 (2008-2011)

Get access

ALTERNATOR EVAP CANISTER PURGE VALVE BLK WIRE BLK/YEL WIRE BRAKE PEDAL POSITION SWITCH CMP SENSOR A ELD UNIT FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 2 OF 4) FROM UNDERDASH FUSE/RELAY BOX (DIAGRAM 3 OF 4) FRONT POWER PASSENGER'S WINDOW POWER MASTER WINDOW SWITCH SWITCH FUSE FUSE 22 FUSE 24 FUSE 23 FUSE 25 FUSE 4 FUSE 6 GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE J/C MAF/IAT SENSOR POWER WINDOW MASTER SWITCH POWER WINDOW RELAY SECONDARY UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) VSA MODULATOR CONTROL UNIT YEL/GRN WIRE

Go to component: -> Power distribution circuit (4 of 4) -> FRONT POWER PASSENGER'S WINDOW POWER MASTER WINDOW SWITCH SWITCH
