Honda Element YH2 facelift 2 (2008-2011) bus sh Wiring diagram

This page shows the only wiring diagram for the component.bus sh, which is found in the car Honda Element YH2 facelift 2 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram bus sh (1 of 1)

Wiring diagram bus sh for Honda Element YH2 facelift 2 (2008-2011)

Get access

AUDIO L+ AUDIO NAVIGATION UNIT (NAVIGATION) AUDIO R- AUDIO SH AUDIO UNIT (EX, SC: W/O NAVIGATION) BLU WIRE BRN WIRE BUS - BUS SH EX, SC GRN WIRE GRY WIRE NAVIGATION PNK WIRE RED WIRE USB ADAPTER UNIT W/ NAVIGATION W/O NAVIGATION WHT WIRE XM RECEIVER (BEHIND RIGHT QUARTERPANEL)

Go to component: -> Ga-net bus/ga-net audio circuit -> BUS SH
