Honda Element YH2 facelift 2 (2008-2011) aux det Wiring diagram
This page shows the only wiring diagram for the component.aux det, which is found in the car Honda Element YH2 facelift 2 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aux det (1 of 1)
A/C GND
AMPLIFIER
AUDIO REMOTE- NAVIGATION VOICE CONTROL SWITCH STEERING WHEEL
AUDO NAVIGATION UNIT
AUX DET
AUX GND
AUX LCH
AUX RCH
AUX S GND
AUX S GND SH GND AUX- GND
AUXILIARY JACK ASSEMBLY
BACK SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (UNDER STEERING COLUMN COVER)
CAMERA GND CAMERA V CAMERA SH CAMERA ADAPT
CAMERA VCC
CHANNEL SWITCH
GPS ANTENNA (UNDER MIDDLE OF DASH)
GPS GPS SH
GRN WIRE
GRN/RED WIRE
GRY WIRE
INTERIOR LIGHT SWITCH
LT GRN/RED WIRE
MIC ADPT
MIC GND
MIC GND MIC SIG SH GND
MIC SIG
MICROPHONE
MODE SWITCH
NAVI GUIDE MIC ADPT
NCA WIRE
REAR CAMERA CIRCUIT
RED WIRE
RR OUT (-) AUX- LCH AUX- RCH AUX- DET
TALK SWITCH
USB DATA -
USB GND
USB JACK
USB SH
USB V BUS
VCC GND
VOLUME DOWN SWITCH
VOLUME UP SWITCH
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (3 of 3) -> AUX DET
