Car Wiring Diagrams for Forced entry circuit for Honda Element YH2 (2003-2006)

BACK UP +B BLK WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE COMBINATION SWITCH DRIVER'S DOOR SWITCH DRL H/L SW LIGHTING RLY FRONT PASSENGER'S DOOR SWITCH FUSE 10 FUSE 7 FUSE 9 GRN WIRE GRN/BLK WIRE HATCH LATCH SWITCH HEADLIGHT SWITCH HORN HORN RELAY HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY SWITCH IGNITION KEY SWITCH/KEY LIGHT JUNCTION CONNECTOR 456 (UNDER CENTER OF DASH) KEY SW K/L UNSET K/L SET KEYLESS RECEIVER UNIT (OPTIONAL) (UNDER CENTER OF DASH) LEFT TAILGATE SWITCH LT GRN/BLK WIRE MICROPHONE MULTIPLEX CONTROL UNIT NCA WIRE ORG/ WIRE RED WIRE RED/WHT WIRE RIGHT TAILGATE SWITCH SECURITY CONTROL UNIT (UNDER LEFT SIDE OF DASH) SECURITY LED SMALL LT RLY- TRUNK SW FR DOOR SW OTHER DOOR SW HORN SW UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE WHT/RED WIRE YEL WIRE
