Honda Element YH2 (2003-2006) Manual a/c circuit

A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY (EX, CANADA DX) A/C PRESS SW A/C PRESSURE SWITCH (ON RIGHT SIDE OF ENGINE COMPARTMENT) AIR MIX CONTROL MOTOR (UNDER LEFT SIDE OF DASH) BLK WIRE BLK/YEL WIRE BLOWER PWR TRANS BLOWER FEEDBACK ILLUMINATION ILLUMINATION REAR DEFOG MODE 4 BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE DEFOGGER SYSTEM ECM/PCM (BEHIND GLOVE BOX) ECU BUS + EVAP SENSOR (+) EVAPORATOR TEMPERATURE SENSOR (UNDER LEFT SIDE OF DASH) (EX, CANADA DX) FRS FUSE 1 FUSE 14 GRN WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HEATER CONTROL PANEL HOT AT ALL TIMES HOT IN ON LT BLU WIRE LT GRN WIRE M- HOT M- COOL AMD- M- VENT M- DEF MODE 3 MODE 2 MODE 4 MODE CONTROL MOTOR (BEHIND GLOVE BOX) MULTIPLEX CONTROL UNIT PNK WIRE PNK/BLK WIRE PNK/BLU WIRE REC RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/YEL WIRE RELAY CTRL COMMUNICATION FAN CONTROL S- COM MODE 1 S-COM SENSOR GROUND AIR MIX POTENTIAL MODE DEF MODE VENT TO BLOWER MOTOR RELAY (DIAGRAM 2 OF 2) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

A/C CONDENSER FAN MOTOR (AT FRONT OF ENGINE COMPARTMENT) (EX, CANADA DX) A/C CONDENSER FAN RELAY (EX, CANADA DX) BLK WIRE BLOWER MOTOR (UNDER RIGHT SIDE OF DASH, ON BLOWER UNIT) BLOWER MOTOR RELAY BLOWER POWER TRANSISTOR (UNDER RIGHT SIDE OF DASH, ON HEATER UNIT/CORE) BLU WIRE BLU/RED WIRE BLU/YEL WIRE FROM A/C COMPRESSOR CLUTCH RELAY (DIAGRAM 1 OF 2) FUSE 1 FUSE 12 FUSE 4 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES RADIATOR FAN MOTOR (AT FRONT OF ENGINE COMPARTMENT) RADIATOR FAN RELAY RADIATOR FAN SWITCH (AT FRONT OF ENGINE COMPARTMENT) RED WIRE SOLID STATE UNDERHOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE
