Honda Element YH2 (2003-2006) left front impact sensor Wiring diagram
This page shows the only wiring diagram for the component.left front impact sensor, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front impact sensor (1 of 1)
A/T
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CANADA
COMBINATION LIGHT SWITCH
CRUISE CONTROL ACTUATOR
ELD UNIT
GRN WIRE
IGNITION KEY SWITCH/ KEY LIGHT
LEFT FRONT IMPACT SENSOR
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL/ PARKING LIGHTS
MULTIPLEX CONTROL UNIT
MULTIPLEX CONTROL UNIT SERVICE CHECK CONNECTOR
PARK PIN SWITCH
POWER STEERING PRESSURE (PSP) SWITCH
POWER WINDOW RELAY
RADIATOR FAN MOTOR
RADIATOR FAN SWITCH
REAR WINDOW WASHER MOTOR
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHTS
SRS UNIT
TURN SIGNAL/ HAZARD RELAY
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX BLOWER MOTOR RELAY
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR
WIPER/ WASHER SWITCH
Go to component: -> Ground distribution circuit (2 of 4) -> LEFT FRONT IMPACT SENSOR
