Honda Element YH2 (2003-2006) left brake light/ taiillight Wiring diagram
This page shows the only wiring diagram for the component.left brake light/ taiillight, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left brake light/ taiillight (1 of 1)
BACK-UP LAMPS CIRCUIT
BLK WIRE
BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT)
BRN WIRE
CRUISE CONTROL UNIT
FROM TAIILLIGHT RELAY (DIAGRAM 1 OF 2)
FROM UNDERDASH ASSEMBLY FUSE/REALY BOX 1 OF 2)
FROM UNDERDASH FUSE/REALY BOX (DIAGRAM 1 OF 2)
FUSE 7
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/YEL WIRE
HIIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
JUNCTION
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAIILLIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT ASSEMBLY
LICENSE PLATE LIGHT
RED WIRE
RED/YEL WIRE
RIGHT BACK-UP LIGHT RIGHT BRAKE LIGHT/ TAIILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT ASSEMBLY
TRAILER CONNECTOR
TRAILER LIGHTING CONNECTOR 1 (AT RIGHT REAR QUARTER PANEL)
TRAILER LIGHTING CONNECTOR 2 (AT RIGHT REAR QUARTER PANEL)
TRAILER LIGHTING IN-LINE FUSE
TRAILER UNIT
UNDERHOOD FUSE/RELAY BOX (AT LEFT REAR OF ENGINE COMPARTMENT)
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit (2 of 2) -> LEFT BRAKE LIGHT/ TAIILLIGHT
