Honda Element YH2 (2003-2006) fog light on indicator wiring diagram
This page shows the only wiring diagram for the component.fog light on indicator, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
fog light on indicator wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER HI
DIMMER SWITCH
DRL H/L SW
FOG LIGHT IN-LINE FUSE (UNDER LEFT SIDE OF DASH)
FOG LIGHT ON INDICATOR
FOG LIGHT RELAY (UNDER LEFT SIDE OF DASH)
FOG LIGHT SWITCH
FOG LIGHT SWITCH LIGHT
FUSE 14
FUSE 15
FUSE 17
FUSE 19
GAUGE ASSEMBLY
HEADLIGHTS RELAY 1
HEADLIGHTS RELAY 2
HEADLT HI
HEADLT LOW
HIGH BEAM INDIC
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT
LIGHT RELAY
MULTIPLEX CONTROL UNIT
OFF FLASH-TO- PASS SWITCH
OFF HEADLIGHT SWITCH
OFF ON
PARK
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
SECURITY CONTROL UNIT CONNECTOR
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
UNDERHOOD FUSE/RELAY BOX (AT LEFT REAR OF ENGINE COMPARTMENT)
WHT WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Headlights circuit, without drl -> FOG LIGHT ON INDICATOR
