Honda Element YH2 (2003-2006) driver's switch 0=off 1=on 2=down 3=auto up 4=auto down Wiring diagram

This page shows the only wiring diagram for the component.driver's switch 0=off 1=on 2=down 3=auto up 4=auto down, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver's switch 0=off 1=on 2=down 3=auto up 4=auto down (1 of 1)

Wiring diagram driver's switch 0=off 1=on 2=down 3=auto up 4=auto down for Honda Element YH2 (2003-2006)

Get access

BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE DOWN DOWN UP OFF OFF DRIVER'S POWER WINDOW MOTOR DRIVER'S SWITCH 0=OFF 1=ON 2=DOWN 3=AUTO UP 4=AUTO DOWN FRONT PASSENGER'S POWER WINDOW SWITCH FUSE 13 FUSE 22 FUSE 23 FUSE 6 GRN/BLK WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE MAIN SWITCH MIL CONTROL DOWN OFF OFF DOWN UP ORG/ WIRE PASSENGER'S POWER WINDOW MOTOR PASSENGER'S POWER WINDOW SWITCH POWER WINDOW MASTER SWITCH POWER WINDOW RELAY PULSER RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SGND PLSB SVCC PLSA UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UP (+) WHT WIRE WHT/BLK WIRE YEL WIRE YEL/GRN WIRE

Go to component: -> Power windows circuit -> DRIVER'S SWITCH 0=OFF 1=ON 2=DOWN 3=AUTO UP 4=AUTO DOWN
