Honda Element YH2 (2003-2006) down up off off wiring diagram
This page shows the only wiring diagram for the component.down up off off, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
down up off off wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DOWN
DOWN UP OFF OFF
DRIVER'S POWER WINDOW MOTOR
DRIVER'S SWITCH 0=OFF 1=ON 2=DOWN 3=AUTO UP 4=AUTO DOWN
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 13
FUSE 22
FUSE 23
FUSE 6
GRN/BLK WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
MAIN SWITCH
MIL CONTROL DOWN
OFF OFF DOWN UP
ORG/ WIRE
PASSENGER'S POWER WINDOW MOTOR
PASSENGER'S POWER WINDOW SWITCH
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PULSER
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SGND PLSB
SVCC PLSA
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UP (+)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Power windows circuit -> DOWN UP OFF OFF
