Honda Element YH2 (2003-2006) down/ right up/ left wiring diagram
This page shows the only wiring diagram for the component.down/ right up/ left, which is found in the car Honda Element YH2 (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
down/ right up/ left wiring diagram (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
DOWN/ LEFT
DOWN/ RIGHT UP/ LEFT
FUSE 14
GRN WIRE
HOT IN ON
LEFT POWER MIRROR
LEFT/ RIGHT MOTOR
POWER MIRROR SWITCH
POWER MIRROR SWITCH LIGHT
RED WIRE
RIGHT LEFT
RIGHT POWER MIRROR
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
UP LEFT DOWN RIGHT
UP/ DOWN MOTOR
UP/ DOWN MOTOR LEFT/ RIGHT MOTOR
UP/ RIGHT
WHT WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> DOWN/ RIGHT UP/ LEFT
