Honda Element YH2 (2003-2006) abs indicator circuit abs ind Wiring diagram

+B-V FR-GND FR +B 14 9 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH) ABS INDICATOR CIRCUIT ABS IND ABS MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT) BLK WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE BRN WIRE BRN/WHT WIRE BRN/YEL WIRE BUS METER EBD EBD FUSE 10 FUSE 11 FUSE 18 FUSE 7 GAUGE ASSEMBLY GND V GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT IN ON HOT IN RUN OR START INSTRUMENT CLUSTER SYSTEM (BRAKE SYSTEM INDICATOR) LEFT FRONT WHEEL SENSOR (FRONT SUSPENSION KNUCKLE) LEFT REAR WHEEL SENSOR (FRONT SUSPENSION KNUCKLE) MULTIPLEX CONTROL SYSTEM ORG/ WIRE RED WIRE RIGHT FRONT WHEEL SENSOR (FRONT SUSPENSION KNUCKLE) RIGHT REAR WHEEL SENSOR (FRONT SUSPENSION KNUCKLE) RL B+ RL GND SCS STOP RR-GND RR +B ABS FL +B FL-GND GND-P UNDERDASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
