Honda Element I (2004-2009) up/ down motor left/ right motor Wiring diagram

This page shows the only wiring diagram for the component.up/ down motor left/ right motor, which is found in the car Honda Element I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram up/ down motor left/ right motor (1 of 1)

Wiring diagram up/ down motor left/ right motor for Honda Element I (2004-2009)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE DOWN/ LEFT DOWN/ RIGHT UP/ LEFT FUSE 14 GRN WIRE HOT IN ON LEFT POWER MIRROR UP/ DOWN MOTOR (FRONT OF DRIVER'S DOOR) LEFT/ RIGHT MOTOR POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RIGHT LEFT RIGHT POWER MIRROR (FRONT OF FRONT PASSENGER'S DOOR) SWITCH 1 SWITCH 2 SWITCH 3 UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UP LEFT DOWN RIGHT UP/ DOWN MOTOR LEFT/ RIGHT MOTOR UP/ RIGHT WHT WIRE YEL WIRE

Go to component: -> Power mirrors circuit -> UP/ DOWN MOTOR LEFT/ RIGHT MOTOR
