Honda Element I (2004-2009) lsa lsc lsb Wiring diagram

A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE B A/T INDICATOR DRIVE CIRCUIT A/T REVERSE RELAY (BEHIND GLOVE BOX) APP SENSOR (RIGHT REAR CORNER OF APSB APSA ECT 1 ATP-P ATPR ATPN ATPD ATPRVS ATPFWD BKSW ATPP BLK WIRE BLK/ WHT WIRE BLK/ YEL WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BLU/ BLK WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT) BRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAN-H- CAN-L- CLUTCH TRANS- MISSION FLUID PRESSURE SWITCH (REAR OF TRANSAXLE) COMPULSORY TURNING- ON CIRCUIT COMPUTER DATA LINES SYSTEM CONTROLLER AREA NETWORK CONTROLLER ECT SENSOR 1 (REAR OF CYLINDER HEAD) ENGINE CONTROLS SYSTEM F-CAN SWITCHED TRANSCEIVER B+ FAIL SAFE CIRCUIT FUSE 10 FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) FUSE 17 FUSE 7 FUSE 9 GAUGE CONTROL MODULE GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON OR START ILLUMINATION CONTROL CIRCUIT J/C LSA LSC LSB MAP MAP SENSOR (LEFT SIDE OF INTAKE MANIFOLD) MRLY MULTIPLEX CONTROL UNIT NC NM ATFT SHE SHD SHB SHA SHC ORG/ WIRE OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR (RIGHT FRONT OF TRANSAXLE) PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SHIFT CONTROL SOLENOID VALVES STARTER CUT RELAY TRANSMISSION HOUSING) UNDER- DASH UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
