Honda Element I (2004-2009) license hatch plate latch light switch Wiring diagram
This page shows the only wiring diagram for the component.license hatch plate latch light switch, which is found in the car Honda Element I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license hatch plate latch light switch (1 of 1)
BLK WIRE
DRIVER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT BELT SWITCH
FUEL PUMP
FUEL TANK UNIT
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT REAR DOOR LOWER SWITCH
LEFT REAR DOOR UPPER SWITCH
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILGATE LATCH SWITCH
LEFT TAILLIGHT ASSEMBLY
LICENSE HATCH PLATE LATCH LIGHT SWITCH
ODS UNIT
REAR ACCESSORY POWER SOCKET
REAR HIGH WINDOW MOUNT WIPER BRAKE MOTOR LIGHT
REAR WINDOW DEFOGGER
REAR WINDOW WIPER INTERMITTENT CONTROL UNIT
RIGHT BACK-UP LIGHT
RIGHT LICENSE TAILGATE PLATE LATCH LIGHT SWITCH
RIGHT REAR
RIGHT REAR DOOR LOWER SWITCH
RIGHT REAR DOOR UPPER SWITCH
RIGHT TAILLIGHT ASSEMBLY
RIGHT TURN BRAKE SIGNAL LIGHT/ LIGHT TAILLIGHT
USA: EX, SC
WHT WIRE
XM RECEIVER
Go to component: -> Ground distribution circuit (4 of 4) -> LICENSE HATCH PLATE LATCH LIGHT SWITCH
