Honda Element I (2004-2009) junction connector Wiring diagram

This page shows the only wiring diagram for the component.junction connector, which is found in the car Honda Element I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram junction connector (11 of 11)

Wiring diagram junction connector for Honda Element I (2004-2009)

Get access

A/T BATTERY BLK WIRE BLK/WHT WIRE BLU/WHT WIRE CLUTCH INTERLOCK SWITCH (ON CLUTCH PEDAL SUPPORT) ELD UNIT FUSE 19 FUSE 20 FUSE 21 IGNITION SWITCH JUNCTION CONNECTOR LOCK M/T STARTER STARTER CUT RELAY STARTER MOTOR STARTER SOLENOID TRANSMISSION TRANSMISSION RANGE SWITCH (ON LOWER REAR OF TRANSAXLE) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT WIRE

Go to component: -> Starting circuit -> JUNCTION CONNECTOR
