Honda Element I (2004-2009) circuit/con- troller area network controller Wiring diagrams

This page contains all the electrical diagrams for the component. circuit/con- troller area network controller, in which he is found in the car Honda Element I (2004-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram circuit/con- troller area network controller (1 of 2)

Wiring diagram circuit/con- troller area network controller for Honda Element I (2004-2009) (1 of 2)

Get lifetime access to Honda Element I (2004-2009)

B+ DAY LT BLK WIRE BLU WIRE BLU/RED WIRE BRAKE LEVEL SWITCH CIRCUIT/CON- TROLLER AREA NETWORK CONTROLLER COMBINATION LIGHT SWITCH DIMMER HI DIMMER SWITCH DRL H/L SW DRL IND ELD UNIT FOG LIGHT IND FOG LIGHT SWITCH FUSE 10 FUSE 12 FUSE 15 FUSE 17 FUSE 19 FUSE 3 GAUGE CONTROL MODULE GRN/BLK WIRE GRN/RED WIRE H/L HI H/L LOW HEAD PARK HEAD PARK OFF HEADLIGHT RELAY HIGH BEAM IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START ILL CONTROL CIRCUIT JUNCTION CONNECTOR LEFT HEADLIGHT LIGHT RELAY MULTIPLEX CONTROL UNIT OFF FLASH-TO- PASS SWITCH OFF HEADLIGHT SWITCH ON OFF RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT HEADLIGHT SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT/BLU WIRE YEL RED/ WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Headlights circuit, lx ex with drl (1 of 2) -> CIRCUIT/CON- TROLLER AREA NETWORK CONTROLLER

Wiring diagram circuit/con- troller area network controller (2 of 2)

Wiring diagram circuit/con- troller area network controller for Honda Element I (2004-2009) (2 of 2)

Get lifetime access to Honda Element I (2004-2009)

B+ DAY LT BLK WIRE BLU WIRE BLU/RED WIRE BRAKE LEVEL SWITCH CIRCUIT/CON- TROLLER AREA NETWORK CONTROLLER COMBINATION LIGHT SWITCH DIMMER HI DIMMER SWITCH DRL DIODE DRL H/L SW H/L HI DRL IND DRL RELAY ELD UNIT FLASH TO PASS SWITCH FOG LIGHT IND FOG LIGHT SWITCH FUSE 10 FUSE 12 FUSE 15 FUSE 17 FUSE 19 FUSE 3 GAUGE CONTROL MODULE GRN/BLK WIRE GRN/RED WIRE HEAD PARK OFF HEAD PARK HEADLIGHT RELAY 1 HEADLIGHT RELAY 2 HEADLIGHT SWITCH HIGH BEAM IND HOT AT ALL TIMES HOT IN ON HOT IN ON OR START ILL CONTROL CIRCUIT JUNCTION CONNECTOR LIGHT RELAY MULTIPLEX CONTROL UNIT OFF RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT/BLU WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Headlights circuit, sc with drl (1 of 2) -> CIRCUIT/CON- TROLLER AREA NETWORK CONTROLLER
