Honda Element I (2004-2009) bus gnd Wiring diagram
This page shows the only wiring diagram for the component.bus gnd, which is found in the car Honda Element I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bus gnd (1 of 1)
+B BACK UP
1 2 CAN L CAN H
2 1 MES CONNECTOR (UNDER LEFT SIDE OF DASH)
29 25 2 11 15 CAN-H CAN-L DIAG-II CAN-H CAN-L
AUDIO UNIT (USA: EX, SC)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/YEL WIRE
BUS -
BUS GND
BUS METER
CAN L
CAN-H
CEIVER,
CONTROLLER AREA NETWORK CONTROLLER
DLC (UNDER LEFT SIDE OF DASH)
ECM/PCM (BEHIND GLOVE BOX)
ENGINE COMPT)
F-CAN
FUSE 9 ENGINE COMPT)
GAUGE CONTROL MODULE
GRY WIRE
HOT AT ALL TIMES
IMMOBILIZER CONTROL UNIT RECEIVER (IN STEERING WHEEL COVER)
IMOES UNIT (EXCEPT 2007 USA)
K LINE
LOGIC
LT BLU WIRE
LT GRN/BLK WIRE
MES SCS K-LINE
MULTIPLEX CONTROL MPCS UNIT CHK GND
MULTIPLEX CONTROL UNIT SERVICE CHECK CONNECTOR
PNK WIRE
RED WIRE
RED/WHT WIRE
SCS
SECONDARY
SRS UNIT (BELOW CENTER OF DASH)
TPMS CONTROL UNIT (UNDER MIDDLE OF DASH)
TRANS.)
TRANSCEIVER/
UART
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN)
UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF
VSA MODULATOR- CONTROL UNIT (RIGHT REAR CORNER OF
VSA SENSOR CLUSTER (UNDER CENTER CONSOLE)
WEN
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
XM RECEIVER (USA: EX, SC) (BEHIND RIGHT QUARTERPANEL)
Go to component -> Computer data lines circuit -> BUS GND
