Honda Element I (2004-2009) a/t shift lever illumination/park pin switch Wiring diagram

A/T SHIFT LEVER ILLUMINATION/PARK PIN SWITCH ATP-P BLK WIRE BLK/BLU WIRE BLU/RED WIRE BRAKE PEDAL POSITION SWITCH (ON BRAKE PEDAL SUPPORT) DRIVE INPUT (ATP -N) FUSE 10 FUSE 7 GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMOES UNIT (EXCEPT 2007 USA) INTERLOCK CONTROL OUTPUT (SLS) JUNCTION KEY INTERLOCK SOLENOID KEY LOCK SOL + KEY SW METER MULTIPLEX CONTROL UNIT P-PIN PARK PIN SWITCH PCM (BEHIND GLOVE BOX) RED/WHT WIRE SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) SHIFT LOCK SOLENOID STOP SW SWITCH INPUT (BKSW) TRANSMISSION RANGE SWITCH (ON LOWER REAR OF TRANSAXLE) UNDERDASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE
