Honda Crosstour I facelift (2012-2015) steering angle sensor Wiring diagrams
This page contains all the electrical diagrams for the component. steering angle sensor, in which he is found in the car Honda Crosstour I facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram steering angle sensor (1 of 5)
ANC/ACTIVE SOUND CONTROL UNIT
ANC/ACTIVE SOUND LDW OFF CONTROL UNIT SWITCH
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BOX (UNDER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
CMP SENSOR A
DIODE D
DIODE E
DRIVER'S JUNCTION BOX
DRIVER'S JUNCTION BOX (LEFT SIDE OF DASH)
DRIVER'S MICU
ELD UNIT
ENGINE MOUNT CONTROL SOLENOID VALVE
EVAP CANISTER PURGE VALVE
EVAP ENGINE CANISTER MOUNT PURGE CONTROL VALVE SOLENOID VALVE
FCW/ LDW CAMERA UNIT
FROM IGNITION SWITCH (DIAGRAM 3 OF 7)
FUSE 10
FUSE 11
FUSE 12
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
GAUGE CONTROL MODULE
GRY WIRE
HVAC DISPLAY UNIT/ PASSENGER'S AIR BAG CUTOFF INDICATOR
J/C
LDW OFF SWITCH
MAF SENSOR/ IAT SENSOR
ODS UNIT
PASSENGER'S MICU
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PCM
PNK WIRE
POWER SEAT CONTROL UNIT
PPL
PPL PPL
PPL/ PPL/ PPL/
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR RELAY
RED WIRE
RELAY CIRCUIT BOARD
REVERSE RELAY
SHIFT LOCK SOLENOID
SHIFT LOCK SOLENOID PCM
SRS UNIT
STARTER CUT RELAY
STEERING ANGLE SENSOR
TO FUSE 9 (DIAGRAM 7 OF 7)
TPMS CONTROL UNIT
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
VSA MODULATOR YAW RATE- STEERING CONTROL UNIT ACCELERATION ANGLE SENSOR SENSOR
WHT WIRE
WINDSHIELD REAR WINDOW WASHER MOTOR WASHER MOTOR RELAY RELAY
WINDSHIELD WASHER MOTOR RELAY
WINDSHIELD WIPER MOTOR RELAY
YAW RATE ACCELERATION SENSOR
YEL WIRE
Go to component -> 2.4l, power distribution circuit (6 of 7) -> STEERING ANGLE SENSOR
Wiring diagram steering angle sensor (2 of 5)
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE ENGINE PEDAL MOUNT POSITION CONTROL SWITCH UNIT
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH)
DIODE
DIODE C
DIODE D
DRIVER JUNCTION BOX
DRIVER JUNCTION BOX (LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
ENGINE MOUNT CONTROL UNIT
EPS CONTROL UNIT
EPS VSA CONTROL MODULATOR UNIT CONTROL UNIT
EVAP CANISTER PURGE VALVE
EVAP MAF CANISTER SENSOR/ PURGE IAT VALVE SENSOR
FROM KEYLESS ACCESS CONTROL UNIT (DIAGRAM 2 OF 5)
FROM UNDER-DASH SUB-RELAY BOX (DIAGRAM 2 OF 5)
FRONT ACCESSORY
FRONT ACCESSORY POWER SOCKET RELAY (CIGARETTE LIGHTER RELAY)
FRONT ODS PASSENGER'S UNIT/ AIR BAG OPDS CUTOFF UNIT INDICATOR
FRONT PASSENGER'S AIR BAG CUTOFF INDICATOR
FUSE
FUSE 10
FUSE 11
FUSE 11 FUSE 10
FUSE 13
FUSE 18
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE 7
FUSE 7 FUSE 9
FUSE 9
FUSE FUSE
GRN WIRE
GRY WIRE
J/C
MAF SENSOR/ IAT SENSOR
ODS UNIT/ OPDS UNIT
OPTIONAL CONNECTOR
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PCM
PGM-FI MAIN RELAY 2
PNK WIRE
POWER SEAT CONTROL UNIT
POWER SOCKET RELAY (CIGARETTE LIGHTER RELAY)
PPL
REAR WINDOW WASHER MOTOR RELAY CIRCUIT
REAR WINDOW WIPER MOTOR RELAY
RED WIRE
RELAY CIRCUIT BOARD
REVERSE RELAY
SRS UNIT
STEERING ANGLE SENSOR
TAN WIRE
TO DRIVER'S JUNCTION BOX (DIAGRAM 1 OF 5)
TO FRONT ACCESSORY POWER SOCKET RELAY (DIAGRAM 4 OF 5)
TO KEYLESS ACCESS CONTROL UNIT (DIAGRAM 2 OF 5)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 5)
TRANSMISSION RANGE SWITCH
VSA MODULATOR CONTROL UNIT
WHT WIRE
WINDSHIELD WASHER MOTOR RELAY CIRCUIT
YAW RATE ACCELERATION SENSOR
YAW STEERING RATE- ANGLE ACCELERATION SENSOR SENSOR
YEL WIRE
Go to component -> 3.5l, power distribution circuit (3 of 5) -> STEERING ANGLE SENSOR
Wiring diagram steering angle sensor (3 of 5)
16 17 PPL
2.4L
2.4L 3.5L
2.4L 3.5L PASSENGER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
3.5L
3.5L 2.4L
ABS IND (LED)
AUXILIARY UNDER-DASH FUSE HOLDER A
AUXILIARY UNDER-DASH FUSE HOLDER A (3.5L) (LEFT END OF DASH)
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION SWITCH
BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH)
BRAKE SYSTEM IND (LED)
BRN WIRE
CAN CONTROLLER
CAN L
CENTER CONSOLE
CENTER JUNCTION 3.5L BOX (UNDER LEFT SIDE OF DASH)
CENTER JUNCTION BOX
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM 2.4L 3.5L
COMPUTER DATA LINES SYSTEM PNK WIRE
COMPUTER DATA LINES SYSTEM PPL
DRIVER'S JUNCTION BOX
DRIVER'S JUNCTION BOX (LEFT SIDE OF DASH)
DRIVER'S UNDER-DASH FUSE/RELAY BOX
EPS CONTROL UNIT
F-CAN TRANSCEIVER
FUSE 15
FUSE 2-2
FUSE 2-3
FUSE 2.4L (LEFT KICK PANEL) 3.5L
FUSE 5 11
FUSE 6
FUSE 8
FUSE FUSE 2-2 2-3
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX FUSE (LEFT REAR OF ENGINE COMPT)
HOT IN ON OR START
INSTRUMENT CLUSTER 3.5L SYSTEM
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT WHEEL SPEED SENSOR
LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT SUSPENSION KNUCKLE)
LEFT REAR WHEEL SPEED SENSOR
LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB ASSEMBLY)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PARKING BRAKE SWITCH
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PCM
PCM (LEFT FRONT OF ENGINE COMPT)
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
PPL PNK WIRE
RED WIRE
RIGHT FRONT WHEEL SPEED SENSOR
RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT SUSPENSION KNUCKLE)
RIGHT REAR WHEEL SPEED SENSOR
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR (STEERING COLUMN)
STEERING COLUMN)
UNDER-HOOD FUSE/RELAY BOX
VSA IND (LED)
VSA MODULATOR CONTROL UNIT
VSA MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT)
VSA OFF IND
VSA OFF SWITCH
WARNING DRIVE CIRCUIT
WHT WIRE
YAW RATE ACCELERATION SENSOR
YAW RATE- ACCELERATION SENSOR (CENTER CONSOLE)
Go to component -> Anti-lock brakes circuit -> STEERING ANGLE SENSOR
Wiring diagram steering angle sensor (4 of 5)
2.4L
2.4L 3.5L
3.5L
3.5L 2.4L
ANC/ACTIVE SOUND CONTROL UNIT
ANC/ACTIVE SOUND CONTROL UNIT (IF EQUIPPED)
AUDIO UNIT/ AUDIO NAVIGATION UNIT
BLK WIRE
BRN WIRE
CENTER CONSOLE
CENTER JUNCTION BOX
CENTER JUNCTION BOX (UNDER LEFT
DLC
DLC (UNDER LEFT SIDE OF DASH)
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
ENGINE MOUNT CONTROL UNIT
ENGINE MOUNT CONTROL UNIT (3.5L) (LEFT KICK PANEL)
EPS CONTROL UNIT
FCW/LDW CAMERA UNIT
FUSE 15
GAUGE CONTROL MODULE
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
IMMOBILIZER KEYLESS CONTROL UNIT
IMMOBILIZER KEYLESS CONTROL UNIT (IF EQUIPPED) (STEERING COLUMN)
K LINE
KEYLESS ACCESS CONTROL UNIT
KEYLESS ACCESS CONTROL UNIT (IF EQUIPPED)
LT BLU WIRE
ORG/ WIRE
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PASSENGER'S UNDER-DASH FUSE/RELAY BOX (RIGHT KICK PANEL)
PCM
PCM 3.5L (LEFT FRONT OF ENGINE COMPT)
RED WIRE
SIDE OF DASH)
SRS UNIT (MIDDLE OF DASH)
STEERING ANGLE SENSOR
STEERING ANGLE SENSOR (STEERING COLUMN)
STEERING COLUMN)
TPMS CONTROL UNIT
TPMS CONTROL UNIT (LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
VSA MODULATOR CONTROL UNIT GAUGE (RIGHT SIDE CONTROL OF ENGINE MODULE COMPT)
WHT WIRE
YAW RATE ACCELERATION SENSOR
YAW RATE- ACCELERATION SENSOR (CENTER CONSOLE)
Go to component -> Data link connector circuit -> STEERING ANGLE SENSOR
Wiring diagram steering angle sensor (5 of 5)
2.4L
3.5L
3.5L 2.4L
ANC/ACTIVE SOUND CONTROL UNIT
AUDIO NAVIGATION/ UNIT AUDIO UNIT
AUTOMATIC DIMMING INSIDE MIRROR
BEHIND STEERING WHEEL)
BLK WIRE
BRN WIRE
CABLE REEL
CABLE REEL (BEHIND STEERING WHEEL)
CARGO AREA ACCESSORY POWER SOCKET RELAY
CLIMATE CONTROL UNIT
COMBINATION LIGHT SWITCH
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CONSOLE CONSOLE ACCESSORY ACCESSORY POWER SOCKET POWER RELAY SOCKET
DATA LINK CONNECTOR (DLC)
DRIVER'S AUTOMATIC VANITY DIMMING MIRROR INSIDE LIGHT MIRROR
DRIVER'S CLIMATE CONTROL SWITCH
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR TOUCH SENSOR
DRIVER'S MICU
DRIVER'S POSITION MEMORY SWITCH
DRIVER'S POWER POSITION MIRROR MEMORY CONTROL SWITCH UNIT
DRIVER'S POWER WINDOW MOTOR
DRIVER'S SEAT HEATER SWITCH
DRIVER'S UNDER-DASH
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S VANITY MIRROR LIGHT
FCW/LDW CAMERA UNIT
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT DRIVER'S PASSENGER'S SEAT SEAT HEATER HEATER SWITCH SWITCH
FRONT FRONT ACCESSORY ACCESSORY POWER POWER SOCKET SOCKET RELAY
FRONT PASSENGER'S SEAT HEATER SWITCH
FUSE/RELAY BOX (LEFT KICK PANEL)
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
HLF-NAVIGATION VOICE CONTROL SWITCH
HOMELINK UNIT
INDIVIDUAL MAP LIGHTS
INTERFACE DIAL
INTERIOR LIGHT SWITCH (MOONROOF SWITCH)
J/C
KEY INTERLOCK SOLENOID/ IGNITION KEY SWITCH/ IGNITION KEY LIGHT
LEFT POWER MIRROR
LEFT POWER POWER MIRROR MIRROR SWITCH
MULTI INFORMATION DISPLAY UNIT
NAVIGATION SWITCH PANEL
PARK PIN SWITCH/ A/T GEAR POSITION INDICATOR PANEL LIGHT
PASSENGER'S AIR BAG CUTOFF INDICATOR, HVAC DISPLAY UNIT
PASSENGER'S VANITY MIRROR LIGHT
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
SRS UNIT
STEERING ANGLE SENSOR
STEERING YAW RATE TPMS ANGLE ACCELERATION CONTROL SENSOR SENSOR UNIT
STEREO AMPLIFIER
TPMS CONTROL UNIT
VSA OFF SWITCH
W/ MEMORY
W/ NAVIGATION
YAW RATE ACCELERATION SENSOR
Go to component -> Ground distribution circuit (4 of 5) -> STEERING ANGLE SENSOR
