Honda Crosstour I facelift (2012-2015) ignition switch Wiring diagrams
This page contains all the electrical diagrams for the component. ignition switch, in which he is found in the car Honda Crosstour I facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram ignition switch (1 of 2)
A/C COMPRESSOR CLUTCH RELAY
ALTERNATOR
ANC/ACTIVE SOUND CONTROL UNIT
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
DLC
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S JUNCTION BOX
DRIVER'S MICU
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
ELD
ETCS CONTROL RELAY
FCW/LDW CAMERA UNIT
FROM DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 7)
FROM FUSE 3-7 (DIAGRAM 4 OF 7)
FRONT PASSENGER'S DOOR COURTESY LIGHT
FUSE
FUSE 1
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 2
FUSE 20
FUSE 21
FUSE 3
FUSE 4
FUSE 5
FUSE 6
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
IGNITION SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
IMMOBILIZER KEYLESS KEYLESS ACCESS CONTROL CONTROL UNIT UNIT
KEYLESS ACCESS CONTROL UNIT
LOCK
MULTI INFORMATION DISPLAY UNIT
MULTI- ANC/ACTIVE INFORMATION SOUND DISPLAY UNIT CONTROL UNIT
NAVIGATION UNIT
ORG/ WIRE
PASSENGER'S MICU
PASSENGER'S UNDER-DASH FUSE/RELAY BOX
PGM-FI MAIN RELAY 1
POWER DRIVER'S MIRROR DOOR CONTROL COURTSEY UNIT LIGHT
POWER MIRROR CONTROL UNIT
POWER SEAT CONTROL UNIT
POWER SEAT CONTROL UNIT (W/ MEMORY)
POWER WINDOW MASTER SWITCH (DOOR MULTIPLEX CONTROL UNIT)
REAR WINDOW DEFOGGER RELAY
RED WIRE
RIGHT FOG LIGHT
RIGHT FOG LIGHT (IF EQUIPPED)
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT HEADLIGHT (HIGH)
RIGHT HEADLIGHT (LOW)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 7)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 7)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 7)
TO DRIVER'S UNDER-DASH FUSE/RELAY BOX (DIAGRAM 7 OF 7)
TO PASSENGER'S UNDER- DASH FUSE/ RELAY BOX DIAGRAM 5 OF 7)
W/ MEMORY
WHT WIRE
YEL WIRE
Go to component -> 2.4l, power distribution circuit (3 of 7) -> IGNITION SWITCH
Wiring diagram ignition switch (2 of 2)
AUXILIARY UNDER DASH FUSE HOLDER (LEFT END OF DASH)
AUXILIARY UNDER-DASH FUSE HOLDER
BATTERY
BLK WIRE
BLK/YEL WIRE
BLU WIRE
DIODE
DIODE C
DRIVER'S UNDER-DASH FUSE/RELAY BOX
DRIVER'S UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
FUSE 1 1
FUSE 3-1
IGNITION SWITCH
LOCK
LOCK ON
LT GRN WIRE
MAGNETIC SWITCH
POWER DISTRI- BUTION SYSTEM
STARTER
STARTER CUT RELAY
STARTER MOTOR
STARTER MOTOR (TOP LEFT OF REAR ENGINE)
TRANSMISSION ASSEMBLY
TRANSMISSION RANGE SWITCH
TRANSMISSION RANGE SWITCH (TRANSMISSION ASSEMBLY)
UNDER-HOOD FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> 2.4l, starting circuit -> IGNITION SWITCH
