Car Wiring Diagrams for Hands free module circuit, honda accessory for Honda Crosstour I (2009-2012)

+B HFL AUDIO- AUDIO+ HFL COM MIC + +B HFL HFL MUTE GND HFL 5 6 7 8 AUDIO BLK WIRE BLU WIRE BRN WIRE DRIVER'S UNDER-DASH FUSE 16 FUSE 31 FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) GAUGE CONTROL MODULE GND HFL H/BRAKE SW +B HFL GRY WIRE HANDSFREE LINK CONTROL UNIT (FRONT OF ROOF) HANDSFREE LINK SWITCH (FRONT OF ROOF) HANDSFREELINK GROUND HFL COM IG 2 HFL HFL FUSE HFL MUTE HOT AT ALL TIMES HOT IN ON IG 2 HFL LT BLU WIRE LT GRN WIRE OPTION CONNECTOR (NOT USED) ORG/ WIRE PARKING BRAKE SWITCH (UNDER CENTER CONSOLE) PARKING BRAKE SWITCH CONNECTOR RED WIRE WHT WIRE
