Car Wiring Diagrams for Instrument illumination circuit for Honda Crosstour I (2009-2012)

A/T GEAR POSITION INDICATOR LIGHT/ PARK PIN SWITCH (UNDER CENTER CONSOLE) A/T GEAR POSITION INDICATOR PANEL LIGHT AMBIENT LIGHT B-CAN B-CAN MICU HI LO S-GND BLK WIRE BLU WIRE CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S SEAT HEATER SWITCH (IF EQUIPPED) FRONT PASSENGER'S SEAT HEATER SWITCH (IF EQUIPPED) FUSE 2 FUSE 6 GRY WIRE HOMELINK UNIT (IF EQUIPPED) (CENTER FRONT OF ROOF) HOT AT ALL TIMES MOONROOF SWITCH (FRONT CENTER OF ROOF) NAVIGATION UNIT ILL+ ORG/ WIRE PASSENGER'S MICU MICU P-GND PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PNK WIRE RED WIRE RED/BLK WIRE SMALL RLY DR CL- TAILLIGHT CONTROL CIRCUIT TAILLIGHT RELAY VSA OFF SWITCH W/ AUTOMATIC LIGHTING W/ HOMELINK W/ HONDA ACCESSORY W/O AUTOMATIC LIGHTING W/O HONDA ACCESSORY

B CAN B CAN HI LO BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT (W/O NAVIGATION) COMPUTER DATA LINES SYSTEM CONTROL SWITCH (W/ NAVIGATION) DRIVER'S CLIMATE FRONT PASSENGER'S CLIMATE CONTROL SWITCH (W/ NAVIGATION) DRIVER'S JUNCTION BOX (BEHIND LEFT KICK PANEL) DRIVER'S MICU DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) ENGINE COMPT) FUSE 15 FUSE 5 GLOVE BOX LIGHT GND (MICU -S) GND (MICU-P) GRY WIRE H/L GND OFF SMALL (LIGHTING) SW SW SW H/L LO HAZARD WARNING SWITCH/ FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HEAD HEAD OFF PARK AUTO HEADLIGHT SWITCH COMBINATION LIGHT SWITCH HOT AT ALL TIMES HOT IN ON HOT IN ON OR START J/C NAVIGATION DISPLAY UNIT (IF EQUIPPED) OFF ORG/ WIRE PARK AUTO PNK WIRE RED WIRE UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF WHT WIRE

AMBIENT LIGHT IN LINE FUSE AMBIENT LIGHT SWITCH (W/ HONDA ACCESSORY) AREA NETWORK TRANSCEIVER BODY CONTROLLER AUDIO REMOTE SWITCH BLK WIRE BLU WIRE BRIGHTENING SWITCH BRN WIRE CABLE REEL (A: IN STEERING COLUMN) (C: IN STEERING WHEEL) COMPUTER DATA LINES SYSTEM CONTROL CIRCUITS CRUISE CONTROL COMBINATION SWITCH DIMMING SWITCH DRIVER'S AMBIENT LIGHT FRONT PASSENGER'S AMBIENT LIGHT GAUGE CONTROL MODULE GRN/RED WIRE GRY WIRE HFL SWITCH (W/O NAVIGATION) HFL-NAVIGATION ORG/ WIRE PNK WIRE RED WIRE RED/BLU WIRE STEERING WHEEL) VOICE CONTROL SWITCH (W/ NAVIGATION) W/ HANDSFREELINK W/ NAVIGATION WHT WIRE
