Backup lamps circuit for Honda Crosstour I (2009-2012)
Backup lamps circuit
A/T REVERSE DIODE A
A/T REVERSE DIODE B
A/T REVERSE RELAY
ATPR
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR (OPTION CONNECTOR)
BACK LT-
BLK WIRE
DRIVER'S MICU BACK LT-
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FACTORY
FUSE 5
HONDA ACCESSORY
HOT IN ON OR START
J/C
LEFT BACKUP LIGHT
LT BLU WIRE
NAVIGATION UNIT (IF EQUIPPED) (UNDER RIGHT SIDE OF CARGO AREA)
PCM (LEFT FRONT OF ENGINE COMPT)
RED WIRE
RIGHT BACKUP LIGHT
TRANSMISSION HOUSING)
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
WHT WIRE
