Honda Crosstour I (2009-2012) computer data lines system lt ppl Wiring diagram

3 2 5 1 4 STR-D STRB SGND SVCC STR-A ABS IND. ABS/VSA FUSE ABS/VSA MOTOR FUSE BKSW F-CANH F-CANL BLK WIRE BLU WIRE BRAKE FLUID LEVEL SWITCH BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH) BRAKE SYSTEM IND BRN WIRE CENTER JUNCTION BOX (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEM LT PPL CONTROL CIRCUITS DRIVER'S JUNCTION BOX (BEHIND LEFT KICK PANEL) DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) F-CAN TRANSCEIVER F-CANH F-CANL GND FRL- RRL- FUSE FUSE 15 FUSE 5 FUSE 6 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HORN RELAY HOT AT ALL TIMES HOT IN ON OR START LEFT FRONT WHEEL SPEED SENSOR (ON LEFT FRONT SUSPENSION KNUCKLE) LEFT REAR WHEEL SPEED SENSOR (ON LEFT REAR SUSPENSION KNUCKLE) LT BLU WIRE LT GRN WIRE MULTI FUSE 2 ORG/ WIRE PASSENGER'S UNDER- DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL) PCM (LEFT FRONT OF ENGINE COMPT) PNK RRR+ FRL+ RRL+ FRR+ F-CANL K-LINE RRR- WIRE PNK WIRE PPL PPL PNK WIRE RED WIRE RIGHT FRONT WHEEL SPEED SENSOR (ON RIGHT FRONT SUSPENSION KNUCKLE) RIGHT REAR WHEEL SPEED SENSOR (ON RIGHT REAR OF VEHICLE) SGND F-CANH STEERING ANGLE SENSOR (IN STEERING COLUMN) STR-Z STR-B SVCC PPL FRR- STR-A UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) VSA MALFUNCTION ACTIVATION IND VSA MODULATOR CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT) VSA OFF IND VSA OFF SWITCH (BEHIND LEFT SIDE OF DASH) WHT WIRE YAW RATE- ACCELERATION SENSOR (UNDER CENTER CONSOLE)
