Exterior lamps circuit for Honda CR-Z I (2010-2016)

BACKUP LAMPS CIRCUIT BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL ASSEMBLY) ECM/PCM (LEFT SIDE OF ENGINE COMPT) FUSE 1 FUSE 22 FUSE 23 FUSE 24 FUSE 29 HAZARD WARNING SWITCH HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN ON OR START J/C LEFT LICENSE PLATE LIGHT LEFT QUARTERPANEL) LT BLU WIRE LT GRN WIRE MICU OFF PNK WIRE PPL RED WIRE RIGHT LICENSE PLATE LIGHT UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE

AUTO B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM CPU/POWER SUPPLY CIRCUIT CONTROLLER AREA NETWORK CONTROLLER GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEAD HEADLIGHT SWITCH LEFT FRONT TURN SIGNAL/SIDE MARKER LIGHT LEFT POWER MIRROR (IN LEFT REARVIEW MIRROR) LEFT TURN LT BLU WIRE LT GRN WIRE MICU OFF PARK PNK WIRE RED WIRE RIGHT FRONT TURN SIGNAL/SIDE MARKER LIGHT RIGHT POWER MIRROR (IN RIGHT REARVIEW MIRROR) SIGNAL IND SIGNAL IND RIGHT TURN TURN SIGNAL SWITCH UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE
