Backup lamps circuit, cvt for Honda CR-Z I (2010-2016)
Backup lamps circuit, cvt
BLK WIRE
BRN WIRE
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
FUSE 5
HOT IN ON OR START
J/C
LEFT QUARTERPANEL)
LEFT REAR TURN SIGNAL LIGHT/BRAKE LIGHT/TAILLIGHT BACKUP LIGHT/SIDE MARKER LIGHT
LT GRN WIRE
PNK WIRE
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING) FWD
UNDER-DASH FUSE/RELAY MICU BOX (LEFT END OF DASH)
WHT WIRE
