Wiring Diagrams for Honda CR-V VI (2022-2024)

Acoustic vehicle alerting system circuit Grille shutter circuit

Automatic a/c circuit, except hybrid Automatic a/c circuit, hybrid

Anti-lock brakes circuit, except hybrid Anti-lock brakes circuit, hybrid Electric servo brake system circuit

Anti-theft circuit

Body control modules circuit

Computer data lines circuit, except hybrid Computer data lines circuit, hybrid

Cooling fan circuit, except hybrid Cooling fan circuit, hybrid

Cruise control circuit, except hybrid Cruise control circuit, hybrid

Defoggers circuit

Electronic power steering circuit

Wiring diagram engine performance 1.5l turbo

Wiring diagram engine performance 2.0l hybrid, engine controls circuit Wiring diagram engine performance 2.0l hybrid, hybrid system circuit

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit, except hybrid Ground distribution circuit, hybrid

Headlights circuit

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Entry light timer circuit Instrument illumination circuit

Memory systems circuit

Blind spot monitoring circuit Multipurpose camera circuit Navigation circuit, 12 speakers Navigation circuit, 4 & 6 speakers Navigation circuit, 8 speakers Parking assistant circuit

Power distribution circuit, except hybrid Power distribution circuit, hybrid

Power door locks circuit

Automatic day/night mirror circuit Power mirrors circuit

Driver power seat circuit Driver"s lumbar circuit Front heated seats circuit Heated steering wheel circuit Passenger power seat circuit Rear heated seats circuit

Power top/sunroof circuit

Power windows circuit, front power windows auto up/down function Power windows circuit, front & rear power windows auto up/down function

Radio circuit, 12 speakers Radio circuit, 4 & 6 speakers Radio circuit, 8 speakers

Electric parking brake circuit Shift interlock circuit, except hybrid Shift interlock circuit, hybrid

Charging circuit Starting circuit

Supplemental restraints circuit

1.5l turbo, a/t circuit 1.5l turbo, awd circuit

2.0l hybrid, a/t circuit 2.0l hybrid, awd circuit

Power tailgate circuit Tailgate release circuit

Warning systems circuit

Front wiper/washer circuit Rear wiper/washer circuit

12 VOLT BATTERY ANTI-LOCK BRAKES SYSTEM AUDIO ACC DIODE AUDIO BACK LT DIODE B-CAN TRANSCEIVER BATTERY CONDITION MONITOR MODULE BATTERY MODULE 1 BATTERY MODULE 2 BYPASS RESISTOR DIODE A DIODE B DOOR LOCK DOOR LOCK KNOB F-CAN TRANSCEIVER IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LIN TRANSCEIVER ON BATTERY) STARTER MAGNET DIODE STEREO AMPLIFIER UN LOCK

(LOWER LEFT REAR OF ENGINE COMPT, A/C CONDENSER FAN MOTOR BLOWER MOTOR CLOSER MOTOR COOLING FAN MOTOR DOOR LOCK ACTUATOR DRIVER'S AIR MIX CONTROL MOTOR DRIVER'S POWER LUMBAR SUPPORT FORWARD/BACKWARD MOTOR DRIVER'S POWER SEAT HEIGHT MOTOR DRIVER'S POWER SEAT RECLINE MOTOR DRIVER'S POWER SEAT SLIDE MOTOR DRIVER'S POWER SEAT TILT MOTOR DRIVER'S POWER WINDOW MOTOR ELECTRIC ENGINE COOLANT PUMP ELECTRIC VTC MOTOR ENGINE CONTROLS SYSTEM FRONT PASSENGER'S POWER WINDOW MOTOR FRONT PASSENGER'S SEAT RECLINE MOTOR FRONT PASSENGER'S SEAT SLIDE MOTOR FUEL FILL DOOR LOCK ACTUATOR GENERATOR MOTOR HEIGHT MOTOR LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR LEFT REAR POWER WINDOW MOTOR MIRROR ACTUATOR MODE CONTROL MOTOR PASSENGER'S AIR MIX CONTROL MOTOR POWER TAILGATE MOTOR RADIATOR FAN MOTOR REAR DIFFERENTIAL PUMP MOTOR REAR WINDOW WIPER MOTOR RECIRCULATION CONTROL MOTOR RECLINE MOTOR RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR RIGHT REAR POWER WINDOW MOTOR SLIDE MOTOR TAILGATE RELEASE ACTUATOR THROTTLE ACTUATOR TILT MOTOR TRACTION MOTOR TURBOCHARGER WASTEGATE CONTROL ACTUATOR WINDSHIELD/ REAR WASHER MOTOR WINDSHIELD/ REAR WINDOW WASHER MOTOR

FRONT INTERIOR LF ANTENNA GNSS ANTENNA LF ANTENNA MIDDLE INTERIOR LF ANTENNA REAR BUMPER LF ANTENNA REAR INTERIOR LF ANTENNA ROOF ANTENNA ROOF ANTENNA SHIELD

REAR VIEW CAMERA

CARGO AREA ACCESSORY POWER SOCKET DUMMY CONNECTOR FRONT ACCESSORY POWER SOCKET OPTIONAL CONNECTOR A

BODY CONTROL MODULE GAUGE CONTROL MODULE RELAY CONTROL MODULE RELAY CONTROL MODULE UNDER-HOOD FUSE/RELAY BOX TRANSMISSION CONTROL MODULE

A/C CONDENSER FAN MOTOR/ RFC UNIT A/C CONDENSER FAN MOTOR/RFC UNIT ACOUSTIC VEHICLE ALERTING CONTROL UNIT ACTIVE NOISE CANCELLATION UNIT AUDIO UNIT AUDIO UNIT MODULE AWD CONTROL UNIT BODY CONTROL UNIT CENTER DISPLAY UNIT CLIMATE CONTROL UNIT CONTROL UNIT) COOLING FAN MOTOR A/C CONDENSER FAN MOTOR/RFC UNIT DOOR MULTIPLEX CONTROL UNIT DOOR MULTIPLEX CONTROL UNIT POWER WINDOW MASTER SWITCH ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR ELECTRIC SERVO BRAKE CONTROL UNIT/PEDAL FEEL SIMULATOR EPS MOTOR/ CONTROL UNIT FRONT SEAT HEATER CONTROL UNIT FRONT USB CHARGER UNIT FUEL TANK UNIT HEATED STEERING WHEEL CONTROL UNIT LEFT SIDE BSI RADAR UNIT LIGHTING CONTROL UNIT MOONROOF MOTOR/ CONTROL UNIT MULTI-PURPOSE CAMERA UNIT POWER SEAT CONTROL UNIT POWER TAILGATE CLOSER UNIT POWER TAILGATE CONTROL UNIT RADIATOR FAN MOTOR/ RFC UNIT RADIATOR FAN MOTOR/RFC UNIT REAR SEAT HEATER CONTROL UNIT REAR USB CHARGER UNIT RIGHT SIDE BSI RADAR UNIT SRS UNIT TELEMATICS CONTROL UNIT VSA MODULATOR CONTROL UNIT WINDSHIELD WIPER CONTROL UNIT/ MOTOR WINDSHIELD WIPER CONTROL UNIT/MOTOR

FUSE 1 FUSE 2 FUSE 2-1 FUSE 2-3 FUSE 2-4 FUSE 2-5 FUSE 2-7 FUSE 3 FUSE 3-1 FUSE 3-2 FUSE 3-3 FUSE 3-4 FUSE 3-6 FUSE 3-7 FUSE 4 FUSE 4-1 FUSE 4-2 FUSE 4-3 FUSE 4-4 FUSE 4-5 FUSE 4-6 FUSE 4-7 FUSE 5 FUSE 5-1 FUSE 5-2 FUSE 5-3 FUSE 5-5 FUSE 5-6 FUSE 5-7 FUSE 6 FUSE 7 FUSE 9 FUSE 10 FUSE 11 FUSE 12 FUSE 13 FUSE 14 FUSE 15 FUSE 16 FUSE 17 FUSE 18 FUSE 19 FUSE 20 FUSE 21 FUSE 22 FUSE 23 FUSE 24 FUSE 25 FUSE 26 FUSE 27 FUSE 28 FUSE 29 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 36 FUSE 37 FUSE 38 FUSE 39 FUSE 40 FUSE 41 FUSE 42 FUSE 43 FUSE 44 FUSE 45 FUSE 47 FUSE 48 FUSE 49 FUSE 50 FUSE 51 FUSE 52 FUSE 53 FUSE 54 FUSE A FUSE D FUSE E MAIN FUSE

LEFT HEADLIGHT RIGHT HEADLIGHT

DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT- BACK HEATER FRONT PASSENGER'S SEAT BACK HEATER FRONT PASSENGER'S SEAT CUSHION HEATER LEFT REAR SEAT CUSHION HEATER PTC HEATER A PTC HEATER B PTC HEATER CORE RIGHT REAR SEAT CUSHION HEATER STEERING HEATER

DRIVER'S/ FRONT PASSENGER'S SEAT HEATER SWITCH INDICATOR FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR HIGH INDICATOR IMMOBILIZER/ SECURITY INDICATOR INDICATOR 1 KEYLESS ACCESS INDICATOR LEFT TURN SIGNAL INDICATOR LIGHTS ON INDICATOR LOW INDICATOR MIDDLE INDICATOR REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH INDICATOR RIGHT TURN SIGNAL INDICATOR SHIFT POSITION INDICATOR PANEL

LIGHTS ON IND LIGHTS-ON REMINDER IND

ELECTRIC OIL PUMP EVAP LEAK CHECK MODULE VACUUM PUMP HIGH PRESSURE FUEL PUMP HIGH PRESSURE FUEL PUMP SHIELD PCU ELECTRIC COOLANT PUMP VACUUM PUMP

A/C COMPRESSOR CLUTCH RELAY A/C CONDENSER FAN RELAY ACC RELAY BLOWER MOTOR RELAY BRAKE LIGHT RELAY BRAKE LIGHT RELAY RELAY CIRCUIT BOARD BRAKE LIGHT RELAY RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX BYPASS CONTACTOR RELAY CARGO AREA ACCESSORY POWER SOCKET RELAY CLOSE RELAY DC-DC CONVERTER ACC RELAY ELECTRIC OIL PUMP RELAY ELECTRIC VTC RELAY ENGINE EWP RELAY FAN CONTROL RELAY FRONT ACCESSORY POWER SOCKET RELAY FRONT SEAT HEATER RELAY FUSE/ RELAY HOLDER A FUSE/RELAY HOLDER A HEATED STEERING WHEEL RELAY HIGH VOLTAGE CONTACTOR RELAY HIGH VOLTAGE SUB CONTACTOR RELAY HORN RELAY HOT W/ ACC RELAY ENERGIZED HOT W/ ELECTRIC VTC RELAY ENERGIZED HOT W/ PGM-FI SUB RELAY ENERGIZED IGHLDA RELAY IGHLDB RELAY IGNITION COIL RELAY INJECTOR RELAY OPEN RELAY PCU ELECTRIC COOLANT PUMP RELAY PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PGM-FI SUB- RELAY POWER WINDOW RELAY PTC HEATER A RELAY PTC HEATER B RELAY RADIATOR FAN RELAY REAR SEAT HEATER RELAY REAR WINDOW DEFOGGER RELAY REAR WINDOW WASHER MOTOR RELAY RELAY 1 ENERGIZED RELAY CIRCUIT BOARD RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX RELAY ENERGIZED REVERSE RELAY STARTER CUT RELAY 1 STARTER CUT RELAY 2 TAILGATE RELEASE ACTUATOR RELAY UNDER- DASH FUSE/ RELAY BOX UNDER- HOOD FUSE/ RELAY BOX UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WINDSHIELD WASHER MOTOR RELAY WINDSHIELD WASHER MOTOR RELAY RELAY CIRCUIT BOARD

12 VOLT BATTERY SENSOR A/C PRESSURE SENSOR APP SENSOR APP SENSOR A APP SENSOR B AUTOMATIC LIGHTING CONTROL UNIT-SENSOR AUTOMATIC LIGHTING/ RAIN SENSOR BATTERY CURRENT SENSOR BRAKE PEDAL STROKE SENSOR BRAKE PEDAL STROKE SENSOR SHIELD CKP SENSOR CMP SENSOR A CMP SENSOR B CVT DRIVE PULLEY SPEED SENSOR CVT DRIVEN PULLEY PRESSURE SENSOR CVT SPEED SENSOR DRIVER'S SEAT POSITION SENSOR ECT SENSOR 1 ECT SENSOR 2 ENGINE OIL PRESSURE SENSOR EVAP LEAK CHECK MODULE PRESSURE SENSOR EVAPORATOR TEMPERATURE SENSOR FUEL RAIL PRESSURE SENSOR GENERATOR MOTOR ROTOR POSITION SENSOR HALL SENSOR HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/SENSOR HEIGHT POSITION SENSOR HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR 1 HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR 2 HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR 2, 3 HIGH VOLTAGE BATTERY MODULE TEMPERATURE SENSOR 3 HUMIDITY/IN-CAR TEMPERATURE SENSOR IAT SENSOR 2 KNOCK SENSOR KNOCK SENSOR SHIELD LEAK SENSOR LEFT FRONT CENTER SENSOR LEFT FRONT CORNER SENSOR LEFT FRONT IMPACT SENSOR LEFT FRONT WHEEL SPEED SENSOR LEFT REAR CENTER SENSOR LEFT REAR CORNER SENSOR LEFT REAR WHEEL SPEED SENSOR LEFT SIDE IMPACT PRESSURE SENSOR LEFT TAILGATE PINCH SENSOR LOWER HYDRAULIC PRESSURE SENSOR PL MAF SENSOR/ IAT SENSOR 1 MAP SENSOR OUTSIDE AIR TEMPERATURE SENSOR PARKING, BACKUP SENSOR CONTROL UNIT PCU COOLANT TEMPERATURE SENSOR POWER TAILGATE SENSOR PRESSURE SENSOR REAR DIFFERENTIAL FLUID PRESSURE SENSOR REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR RECLINE POSITION SENSOR RIGHT FRONT CENTER SENSOR RIGHT FRONT CORNER SENSOR RIGHT FRONT IMPACT SENSOR RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR CENTER SENSOR RIGHT REAR CORNER SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT SIDE IMPACT PRESSURE SENSOR RIGHT TAILGATE PINCH SENSOR ROCKER ARM OIL PRESSURE SENSOR SLIDE POSITION SENSOR TEMPERATURE SENSOR TILT POSITION SENSOR TORQUE CONVERTER TURBINE SPEED SENSOR TORQUE SENSOR TP SENSOR TRACTION MOTOR ROTOR POSITION SENSOR TRACTION MOTOR TEMPERATURE SENSOR TRANSMISSION FLUID PRESSURE SENSOR TRANSMISSION FLUID TEMPERATURE SENSOR TURBOCHARGER BOOST SENSOR TURBOCHARGER WASTEGATE CONTROL ACTUATOR POSITION SENSOR UPPER HYDRAULIC PRESSURE SENSOR PU WINDSHIELD WASHER LEVEL SENSOR

ACOUSTIC VEHICLE ALERTING SPEAKER ACTIVE NOISE CANCELLATION SPEAKER DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER LEFT REAR DOOR SPEAKER LEFT SATELLITE SPEAKER RIGHT REAR DOOR SPEAKER RIGHT SATELLITE SPEAKER

ACC COMBINATION SWITCH APPLY SWITCH AUDIO REMOTE- HFL SWITCH AUTOMATIC BRAKE HOLD SWITCH BRAKE FLUID LEVEL SWITCH BRAKE PEDAL POSITION SWITCH CANCEL SWITCH CENTER, RIGHT REAR SEAT BELT BUCKLE SWITCH CENTER/RIGHT REAR SEAT BELT BUCKLE SWITCH CLIMATE CONTROL SWITCH COMBINATION LIGHT SWITCH CYLINDER SWITCH DIMMER/ FLASH-TO- PASS SWITCH DISTANCE SWITCH DOOR LOCK SWITCH DOOR SWITCH DRIVE MODE SWITCH/HILL DESCENT CONTROL SWITCH DRIVER'S DOOR LOCK SWITCH DRIVER'S POWER LUMBAR SUPPORT SWITCH DRIVER'S POWER SEAT ADJUSTMENT SWITCH DRIVER'S POWER TAILGATE SWITCH/ HEATED WINDSHIELD WIPER AREA SWITCH DRIVER'S POWER TAILGATE SWITCH/ VSA OFF SWITCH DRIVER'S SEAT BELT BUCKLE SWITCH DRIVER'S SWITCH DRIVER'S/ FRONT PASSENGER'S SEAT HEATER SWITCH DRIVER'S/ FRONT PASSENGER'S SEAT HEATER SWITCH IND DRIVING POSITION MEMORY SWITCH ELECTRIC PARKING BRAKE SWITCH ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH ENGINE START/ STOP SWITCH ENGINE START/STOP SWITCH FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH FRONT PASSENGER'S POWER WINDOW SWITCH FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FRONT PASSENGER'S SWITCH FULL LATCH SWITCH HALF LATCH SWITCH HAZARD WARNING SWITCH HEADLIGHT SWITCH HEATED STEERING WHEEL SWITCH HEIGHT SWITCH HILL DESCENT CONTROL SWITCH HOOD LATCH SWITCH HORN SWITCH IDLE STOP OFF SWITCH IDLE STOP OFF SWITCH/ DRIVE MODE SWITCH/HILL DESCENT CONTROL SWITCH IDLE STOP OFF SWITCH/DRIVE MODE SWITCH/HILL DESCENT CONTROL SWITCH INTERIOR LIGHT SWITCH KNOB SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT BELT BUCKLE SWITCH LEFT REAR SEAT HEATER SWITCH LEFT REAR SWITCH LKAS SWITCH MAGNETIC SWITCH MAIN SWITCH MOONROOF SWITCH NEUTRAL SWITCH PARK PIN SWITCH POWER MIRROR SWITCH POWER SWITCH POWER TAILGATE INSIDE SWITCH POWER WINDOW MASTER SWITCH RATCHET SWITCH REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH IND REAR WIPER/ WASHER SWITCH RECLINE SWITCH RECLINING SWITCH RELEASE SWITCH RES/+ SWITCH RIGHT REAR POWER WINDOW SWITCH RIGHT REAR SEAT HEATER SWITCH RIGHT REAR SWITCH SET SWITCH SLIDE SWITCH TAILGATE LATCH SWITCH TAILGATE LOCK SWITCH TAILGATE OUTER HANDLE SWITCH TILT SWITCH TRANSMISSION RANGE SWITCH TURN SIGNAL SWITCH VSA OFF SWITCH VSA OFF SWITCH/ DRIVER'S POWER TAILGATE SWITCH VSA OFF SWITCH/DRIVER'S POWER TAILGATE SWITCH WASHER FLUID LEVEL SWITCH WASHER SWITCH WINDSHIELD WASHER LEVEL SWITCH WIPER SWITCH WIPER/WASHER SWITCH

CANISTER CHANGE OVER VALVE CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE EGR VALVE EVAP CANISTER PURGE VALVE PEDAL FEEL SIMULATOR CUT VALVE REAR DIFFERENTIAL SOLENOID VALVE ROCKER ARM OIL CONTROL VALVE SHIFT LOCK SOLENOID SHIFT SOLENOID VALVE A SHIFT SOLENOID VALVE B SHIFT SOLENOID VALVE C SHIFT SOLENOID VALVE O/P TURBOCHARGER BYPASS CONTROL SOLENOID VALVE VARIABLE CAPACITY CONTROL SOLENOID VTC OIL CONTROL SOLENOID VALVE VTC OIL CONTROL SOLENOID VALVE A VTC OIL CONTROL SOLENOID VALVE B

(OR RED/ WIRE BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE GRN WIRE GRY WIRE LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PNK ON WIRE PNK PNK WIRE PNK PPL WIRE PNK WIRE PPL/BLK WIRE PPL/BLU WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PPL/WHT WIRE PPL/YEL WIRE RED WIRE TAN WIRE WHT WIRE YEL WIRE

0 = LOW 1 = HIGH 2 = PASSING 0) LO 1) HIGH 2) PASSING 0) OFF 1) AUTO 2) PARK 0) OFF 1) AUTO 2) PARK 3) HEAD 0) OFF 1) PARK 2) AUTO 3) HEAD 3) HEAD 4, 6 SPEAKERS (OR (RIGHT SIDE OF TRANSMISSION A/C COMPRESSOR A/C COMPRESSOR CLUTCH ACTIVE BODYWORKS SYSTEM AIR CONDITIONING AIR CONDITIONING SYSTEM AUTO AUTO CLOSE OPEN AUTO CLOSE AUTO DOWN AUTO OPEN AUTO UP AUTO/ INT LOW OFF AUTO/ INT OFF LOW HIGH MIST B-CAN BACKUP LAMPS CIRCUIT BACKUP LIGHT BRAKE LIGHT BSI ALERT IND CABLE REEL CAN CONTROLLER CAN GATEWAY CEILING LIGHT CENTER TRAY LIGHT COMPUTER DATA LINES SYSTEM CONTROL CIRCUIT COOLING FAN COOLING FANS SYSTEM CRUISE CONTROL SYSTEM DC-DC CONVERTER DEFOGGER SYSTEM DOOR KEY DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR, TAILGATE OPEN IND DOWN AUTO DOWN RIGHT DOWN UP DOWN/ RIGHT UP/ LEFT DRIVER'S AIR BAG INFLATOR DRIVER'S DOOR INNER HANDLE LIGHT DRIVER'S DOOR LATCH DRIVER'S DOOR OUTER HANDLE DRIVER'S FOOTWELL LIGHT DRIVER'S KNEE AIR BAG INFLATOR DRIVER'S SEAT BELT OUTER LAP TENSIONER DRIVER'S SEAT BELT TENSIONER DRIVER'S SIDE AIR BAG INFLATOR DRIVER'S VANITY MIRROR LIGHT ELECTRIC A/C COMPRESSOR ELECTRIC A/C COMPRESSOR SHIELD ELECTRIC BRAKE BOOSTER EVAP LEAK CHECK MODULE EVAP LEAK CHECK MODULE SHIELD EXCEPT 8 SPEAKERS EXCEPT EX EXCEPT EXL EXCEPT FH-SE EXCEPT HYBRID EXCEPT HYBRID EX EXCEPT HYBRID EXCEPT EXL EXCEPT HYBRID EXL EXCEPT HYBRID HYBRID EXCEPT LX EXCEPT SPORT F-CAN F-CAN H F-CAN L FH-SE FRONT INDIVIDUAL MAP LIGHT FRONT PARKING/ DAYTIME RUNNING LIGHT FRONT PASSENGER'S AIR BAG INFLATOR FRONT PASSENGER'S DOOR INNER HANDLE LIGHT FRONT PASSENGER'S DOOR LATCH FRONT PASSENGER'S DOOR OUTER HANDLE FRONT PASSENGER'S FOOTWELL LIGHT FRONT PASSENGER'S KNEE AIR BAG INFLATOR FRONT PASSENGER'S SEAT BELT OUTER LAP TENSIONER FRONT PASSENGER'S SEAT BELT TENSIONER FRONT PASSENGER'S SIDE AIR BAG INFLATOR FRONT POSITION/ FRONT PARKING/ DAYTIME RUNNING LIGHT FRONT SIDE MARKER LIGHT HALL-U HALL-V HALL-W HEADLIGHTS SYSTEM HFL MICROPHONE HIGH BEAM HIGH BEAM IND HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT W/ HOT W/ DC-DC HOT W/ DC-DC CONVERTER HOT W/ DC/DC HYBRID (OR HYBRID EXCEPT FH-SE HYBRID EXCEPT HYBRID HYBRID EXCEPT SPORT HYBRID FH-SE HYBRID SPORT IMMOBILIZER/ SECURITY IND INJECTOR 1 INJECTOR 1 SHIELD INJECTOR 2 INJECTOR 2 SHIELD INJECTOR 3 INJECTOR 3 SHIELD INJECTOR 4 INJECTOR 4 SHIELD INNER TAILLIGHT INSTRUMENT CLUSTER SYSTEM INTERMITTENT DWELL TIME CONTROLLER JUNCTION BOARD JUNCTION BOARD SHIELD JUNCTION BOX A JUNCTION BOX B JUNCTION BOX C JUNCTION BOX E JUNCTION BOX F JUNCTION BOX G KEYLESS ACCESS IND KEYLESS BUZZER LEFT "C" PILLAR) LEFT CARGO AREA LIGHT LEFT FRONT ACTIVE NOISE CANCELLATION MICROPHONE LEFT FRONT TWEETER LEFT INNER TAILLIGHT LEFT POWER MIRROR LEFT QUARTERPANEL) LEFT REAR DOOR LATCH LEFT REAR DOOR TWEETER LEFT REAR SEAT BELT TENSIONER LEFT REAR SIDE AIR BAG INFLATOR LEFT REAR TURN SIGNAL LIGHT LEFT SIDE CURTAIN AIR BAG INFLATOR LEFT SIDE TURN SIGNAL LIGHT LEFT TAILLIGHT LEFT TURN SIGNAL IND LICENSE PLATE LIGHT LOW BEAM MAIN/ DR/AS/ RR/RL MCV-P+B MCV-S MCV-S+B MILLIMETER WAVE RADAR MIRROR DEFOGGER MIST HIGH MULTI-INFORMATION DISPLAY NAVIGATION SYSTEM OFF INT OFF OPEN CLOSE ON DOOR PARKING BRAKE REMINDER IND PASSENGER'S VANITY MIRROR LIGHT PFSV+B PLR+ POSITION 1 POSITION 2 POWER DISTRIBUTION SYSTEM POWER MIRROR DEFOGGER POWER TRANSISTOR POWER WINDOWS SYSTEM REAR ACTIVE NOISE CANCELLATION MICROPHONE REAR VIEW MIRROR) REAR VIEW WINDOW REAR WINDOW DEFOGGER RIGHT CARGO AREA LIGHT RIGHT END OF DASH) RIGHT FRONT ACTIVE NOISE CANCELLATION MICROPHONE RIGHT FRONT TWEETER RIGHT INNER TAILLIGHT RIGHT LEFT RIGHT POWER MIRROR RIGHT REAR DOOR LATCH RIGHT REAR DOOR TWEETER RIGHT REAR SEAT BELT TENSIONER RIGHT REAR SIDE AIR BAG INFLATOR RIGHT REAR TURN SIGNAL LIGHT RIGHT SIDE CURTAIN AIR BAG INFLATOR RIGHT SIDE OF RADIATOR) RIGHT SIDE TURN SIGNAL LIGHT RIGHT TAILLIGHT RIGHT TURN SIGNAL IND SEAT BELT REMINDER IND SERVICE PLUG SET- SGND PU PU SHIFT INTERLOCK SYSTEM SHUTTER GRILLE SOUND SYSTEMS SPARK PLUG SRS IND STARTING/CHARGING SYSTEM STEERING WHEEL) SVCC PL SGND PL PL SVCC PU TAILGATE LATCH TAILLIGHT/ SIDE MARKER LIGHT THERMAL JOINT 1 THERMAL JOINT 2 THERMAL JOINT 3 THERMAL JOINT 4 THERMAL JOINT 5 THERMAL JOINT 6 THERMAL JOINT 7 THERMAL JOINT 8 THERMAL JOINT 9 THERMAL JOINT 10 THERMAL JOINT 11 THERMAL JOINT 12 THERMAL JOINT 13 TOP OF TRANSMISSION) TRANSMISSIONS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TURN SIGNAL LIGHT UP AUTO UP DOWN UP LEFT UP/ RIGHT DOWN/ LEFT USB PORT C CHARGE USB PORT D CHARGE USB PORT HOLDER W/ MEMORY W/ MIRROR DEFOGGER, BSI ALERT W/ POWER TAILGATE W/O MIRROR DEFOGGER, BSI ALERT W/O POWER TAILGATE WIPER/WASHER SYSTEM WIRELESS CHARGER
