Automatic a/c circuit, except hybrid for Honda CR-V V facelift (2019-2024)

BLK WIRE BLOWER MOTOR BLU WIRE BRN WIRE CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM DRIVER'S AIR MIX CONTROL MOTOR EVAPORATOR TEMPERATURE SENSOR FRONT BLOWER MOTOR RELAY FUSE 3-1 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE MODE CONTROL MOTOR ORG/ WIRE PNK WIRE POWER TRANSISTOR PPL RECIRCULATION CONTROL MOTOR RED WIRE TAN WIRE UNDER-HOOD FUSE/RELAY BOX W/ DUAL ZONE CONTROL W/O DUAL ZONE CONTROL WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CENTER CONSOLE CLIMATE CONTROL PANEL FUSE 25 FUSE 27 FUSE 31 FUSE 6 FUSE 9 FUSE/RELAY HOLDER A GRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ HOT W/ PGM-FI SUB RELAY ENERGIZED HUMIDITY/IN-CAR TEMPERATURE SENSOR LT BLU WIRE LT GRN WIRE OUTSIDE AIR TEMPERATURE SENSOR PASSENGER'S AIR MIX CONTROL MOTOR PNK WIRE PPL REAR WINDOW DEFOGGER/ MIRROR DEFOGGER SWITCH RED WIRE RELAY HOLDER C HEATED STEERING WHEEL RELAY SRS UNIT SUNLIGHT SENSOR (W/ AUTOMATIC WIPER) TAN WIRE UNDER-DASH FUSE/RELAY BOX W/ DUAL ZONE CLIMATE CONTROL W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM WHT WIRE YEL WIRE

A/C COMPRESSOR CLUTCH RELAY A/C CONDENSER FAN RELAY AUTOMATIC LIGHTING CONTROL UNIT/ SUNLIGHT SENSOR AUTOMATIC LIGHTING/ RAIN SENSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIMMING CIRCUIT ECON MODE IND F-CAN F-CAN F-CAN TRANSCEIVER FAN CONTROL RELAY FUSE 1-3 FUSE 18 FUSE 2-6 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES IDLE STOP OFF SWITCH/ECON SWITCH ILLUMINATION CONTROL LT BLU WIRE PNK WIRE PPL RADIATOR FAN RELAY RED WIRE RELAY HOLDER F UNDER-HOOD FUSE/RELAY BOX WARNING DRIVING CIRCUIT WHT WIRE YEL WIRE

A/C COMPRESSOR (LOWER LEFT FRONT OF ENGINE) A/C COMPRESSOR CLUTCH A/C CONDENSER FAN MOTOR A/C PRESSURE SENSOR AUXILIARY UNDER-DASH FUSE/RELAY BOX BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECT SENSOR 1 ECT SENSOR 2 (BOTTOM LEFT REAR OF RADIATOR) EVAP LEAK CHECK MODULE FUSE 2-6 GRN WIRE GRY WIRE HOT W/ DC-DC LT BLU WIRE ORG/ WIRE PCM PPL RADIATOR FAN MOTOR RED WIRE RELAY 1 ENERGIZED VARIABLE CAPACITY CONTROL SOLENOID WHT WIRE YEL WIRE
