Honda CR-V V facelift (2019-2024) engine block) Wiring diagrams
This page contains all the electrical diagrams for the component. engine block), in which he is found in the car Honda CR-V V facelift (2019-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram engine block) (1 of 2)
12 VOLT BATTERY SENSOR
AUXILIARY TRANSMISSION FLUID PUMP
BLK WIRE
CVT
CVT CLUTCH PRESSURE CONTROL SOLENOID VALVE
CVT DRIVE PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT DRIVEN PULLEY PRESSURE CONTROL SOLENOID VALVE
CVT LOCK-UP CLUTCH CONTROL SOLENOID VALVE
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT POSITION SENSOR
ENGINE BLOCK)
EVAP LEAK CHECK MODULE
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT FRONT PASSENGER'S SEAT CUSHION HEATER
GRN WIRE
GRY WIRE
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
POWER LUMBAR SUPPORT SWITCH
POWER SEAT CONTROL UNIT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT SIDE BSI RADAR UNIT
RIGHT TAILLIGHT
TCM
TOP OF TRANSMISSION)
TRANSMISSION HOUSING)
TRANSMISSION RANGE SWITCH
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit, except hybrid (4 of 5) -> ENGINE BLOCK)
Wiring diagram engine block) (2 of 2)
14 PIN CONNECTOR
ANC/ACTIVE SOUND CONTROL UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC BRAKE HOLD SWITCH/ELECTRIC PARKING BRAKE SWITCH
AUTOMATIC LIGHTING CONTROL UNIT/ SUNLIGHT SENSOR
BLK WIRE
BRN WIRE
CENTER DISPLAY UNIT
CLIMATE CONTROL PANEL/ FRONT PASSENGER AIR BAG CUTOFF INDICATOR
CLIMATE CONTROL UNIT
CONSOLE ACCESSORY POWER SOCKET
ECON SWITCH
ENGINE BLOCK)
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
HAZARD WARNING SWITCH
HEATED STEERING WHEEL RELAY
HIGH MOUNT BRAKE LIGHT
IMA BATTERY CASE
KEYLESS BUZZER
LEFT BACKUP LIGHT
LEFT INNER TAILLIGHT
LEFT QUARTERPANEL)
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT
LICENSE PLATE LIGHT/TAILGATE OUTER HANDLE/ LOCK SWITCH
OPTION CONNECTOR (FOR TRAILER)
PARKING, BACKUP SENSOR CONTROL UNIT
POWER TAILGATE CONTROL UNIT
PPL
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT BACKUP LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
SBW SHIFTER CONTROL MODULE
SPORT MODE/ ECON/EV SWITCH
STEREO AMPLIFIER
TAILGATE LATCH
TRANSMISSION HOUSING)
USB CHARGER UNIT
W/ KEYLESS ACCESS SYSTEM
WIRELESS CHARGER
Go to component -> Ground distribution circuit, hybrid (4 of 4) -> ENGINE BLOCK)
