Honda CR-V V (2016-2022) license plate light/tailgate outer handle/ lock switch Wiring diagram
This page shows the only wiring diagram for the component.license plate light/tailgate outer handle/ lock switch, which is found in the car Honda CR-V V (2016-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license plate light/tailgate outer handle/ lock switch (1 of 1)
ANC/ACTIVE SOUND CONTROL UNIT
AUDIO- NAVIGATION UNIT
AUTOMATIC LIGHTING CONTROL UNIT/ SUNLIGHT SENSOR
BLK WIRE
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET
CARGO AREA ACCESSORY POWER SOCKET RELAY
CENTER DISPLAY UNIT
CLIMATE CONTROL PANEL
CLIMATE CONTROL UNIT
CONSOLE ACCESSORY POWER SOCKET
CONSOLE BOX LIGHT
ECON SWITCH
ELECTRIC PARKING BRAKE SWITCH
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT SEAT HEATER CONTROL UNIT
GRY WIRE
HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
HAZARD WARNING SWITCH
HEATED STEERING WHEEL RELAY
HIGH MOUNT BRAKE LIGHT
KEYLESS BUZZER
LEFT BACKUP LIGHT
LEFT INNER TAILLIGHT
LEFT QUARTERPANEL)
LEFT REAR SEAT CUSHION HEATER
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT
LICENSE PLATE LIGHT/ TAILGATE OUTER HANDLE/ LOCK SWITCH
LICENSE PLATE LIGHT/TAILGATE OUTER HANDLE/ LOCK SWITCH
POWER TAILGATE CONTROL UNIT
POWER TAILGATE LATCH
PPL
REAR SEAT HEATER CONTROL UNIT
REAR SEAT HEATER RELAY
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RELAY HOLDER C
RIGHT BACKUP LIGHT
RIGHT INNER TAILLIGHT
RIGHT POWER MIRROR
RIGHT REAR SEAT CUSHION HEATER
SHIFT LEVER)
STEREO AMPLIFIER
USB CHARGER UNIT
W/ KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM
W/O KEYLESS ACCESS SYSTEM W/ KEYLESS ACCESS SYSTEM
Go to component -> Ground distribution circuit (5 of 5) -> LICENSE PLATE LIGHT/TAILGATE OUTER HANDLE/ LOCK SWITCH
