Honda CR-V V (2016-2022) left map light Wiring diagrams
This page contains all the electrical diagrams for the component. left map light, in which he is found in the car Honda CR-V V (2016-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left map light (1 of 3)
6 PIN OPTIONAL CONNECTOR
AMBIENT LIGHT
BLK WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT (W/O PANORAMIC GLASS ROOF)
DOOR
DRIVER'S VANITY MIRROR LIGHT
FRONT INDIVIDUAL MAP LIGHT (W/O PANORAMIC GLASS ROOF)
FUSE 7
FUSE 8
GRN WIRE
GRY WIRE
HOT IN ON OR START
INTERIOR LIGHT SWITCH
INTERIOR LIGHTS
LEFT MAP LIGHT
MAP LIGHT SWITCH
MOONROOF SWITCH/ AMBIENT LIGHT
OFF
ON OFF
PASSENGER'S VANITY MIRROR LIGHT
PPL
RED WIRE
RIGHT MAP LIGHT
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
Go to component -> Courtesy lamps circuit (1 of 3) -> LEFT MAP LIGHT
Wiring diagram left map light (2 of 3)
AMBIENT LIGHT
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
DRIVER'S DOOR SWITCH
ELECTRIC BRAKE BOOSTER
FRONT PASSENGER'S DOOR SWITCH
GRN WIRE
GRY WIRE
IGNITION KEY
IGNITION KEY SWITCH
LEFT CARGO AREA LIGHT
LEFT MAP LIGHT
LEFT MAP LIGHT SWITCH
LEFT REAR DOOR SWITCH
LIGHT
LT GRN WIRE
PNK WIRE
POWER TAILGATE INSIDE SWITCH
REAR INDIVIDUAL MAP LIGHT
RED WIRE
RIGHT CARGO AREA LIGHT
RIGHT MAP LIGHT
RIGHT MAP LIGHT SWITCH
RIGHT REAR DOOR SWITCH
SWITCH
W/ PANORAMIC GLASS ROOF
W/ PANORAMIC GLASS ROOF W/O PANORAMIC GLASS ROOF
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> LEFT MAP LIGHT
Wiring diagram left map light (3 of 3)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCK KNOB
DOOR MULTIPLEX CONTROL UNIT
DRIVE CIRCUIT
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
FULL LATCH SWITCH
GRN WIRE
IMMOBILIZER KEYLESS CONTROL UNIT
INTERIOR LIGHT SWITCH
INTERIOR LIGHTS
KEY
LEFT MAP LIGHT
LEFT MAP LIGHT SWITCH
LEFT QUARTERPANEL)
LOCK
LT BLU WIRE
MAP LIGHT SWITCH
PNK WIRE
POWER TAILGATE CLOSER UNIT
POWER TAILGATE CONTROL UNIT
POWER TAILGATE LATCH
POWER WINDOW MASTER SWITCH
REAR INDIVIDUAL MAP LIGHT
RED WIRE
RIGHT MAP LIGHT
RIGHT MAP LIGHT SWITCH
TAILGATE LATCH SWITCH
UNLOCK
W/ PANORAMIC GLASS ROOF
W/ POWER TAILGATE
W/O KEYLESS ACCESS SYSTEM
W/O POWER TAILGATE
WHT WIRE
Go to component -> Entry light timer circuit (2 of 2) -> LEFT MAP LIGHT
