Car Wiring Diagrams for Chime circuit for Honda CR-V IV (2011-2015)

AMP B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRAKE INDICATOR BRN WIRE CAN L CIRCUIT COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM CONVERTER) DC/DC - DIMMING DOOR INDICATOR DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) DRIVER'S JUNCTION BOX 2 (LEFT SIDE OF DASH) DRIVER'S MICU EXCEPT LX W/O NAVIGATION, W/O RES PNK WIRE EXL W/O NAVIGATION, W/ RES, EXL W/ NAVIGATION, W/O RES F-CAN TRANSCEIVER FAIL-SAFE FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) FUSE GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD HOT AT ALL TIMES UNDER- HOOD FUSE/ FUSE RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) HOT IN ACC OR ON HOT IN ON OR START IGNITION KEY SWITCH INDICATOR DRIVE CIRCUIT LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LIGHTS ON INDICATOR LOW OIL PRESSURE INDICATOR LT GRN WIRE MIXING OIL PRESSURE SWITCH (ON RIGHT FRONT OF ENGINE, ABOVE OIL FILTER) ORG/ WIRE PARKING BRAKE SWITCH (UNDER LEFT SIDE OF DASH) PCM (LEFT SIDE OF ENGINE COMPT) PNK WIRE POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER RED WIRE RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) SEAT BELT REMINDER INDICATOR SPEAKER SRS UNIT (UNDER FRONT OF CENTER CONSOLE) STABILLZING TAILGATE INDICATOR TURNING-ON FORCED UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH) W/ RES WHT WIRE YEL WIRE
