Base radio circuit for Honda CR-V IV (2011-2015)

AM/FM/XM ANTENNA AUDIO UNIT/AUDIO NAVIGATION UNIT AUXILIARY JACK ASSEMBLY BLK WIRE BLU WIRE BOX (CENTER OF DASH) BRN WIRE CENTER JUNCTION COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX 1 (LEFT SIDE OF DASH) DRIVER'S MICU ELECTRICAL COMPASS UNIT (REAR OF ROOF) FUSE 19 FUSE 2-2 FUSE 25 FUSE 29 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACC OR ON J/C LT BLU WIRE LT GRN WIRE NCA WIRE PNK PNK WIRE PNK WIRE PPL PPL PPL RED WIRE REVERSE RELAY SUB AMPLIFIER TAN WIRE TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING) UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH BLK WIRE BLU WIRE BRN WIRE CABLE REEL (TOP OF STEERING COLUMN) CENTER JUNCTION BOX (CENTER OF DASH) CH- COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE HANDSFREE- LINK CONTROL UNIT INFO LEFT BACK-UP LIGHT LEFT REAR DOOR SPEAKER LT BLU WIRE LT GRN WIRE MENU MULTI INFORMATION DISPLAY UNIT NAVIGATION SYSTEM NCA WIRE ORG/ WIRE PNK PNK WIRE PNK PPL WIRE PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER SOURCE USB PORT VOL DOWN VOL UP WHT WIRE YEL WIRE
