Honda CR-V IV (2011-2015) multi- infromation display unit wiring diagram
This page shows the only wiring diagram for the component.multi- infromation display unit, which is found in the car Honda CR-V IV (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
multi- infromation display unit wiring diagram (1 of 1)
BLK WIRE
BRN WIRE
DRIVER'S JUNCTION 2 (LEFT SIDE OF DASH)
DRIVER'S MICU
FUSE 5
HOT IN ON OR START
J/C
LEFT BACKUP LIGHT
MULTI- INFROMATION DISPLAY UNIT
PCM (LEFT SIDE OF ENGINE COMPT)
PPL
REVERSE RELAY
RIGHT BACKUP LIGHT
TAN WIRE
TRANSMISSION RANGE SWITCH (ON TRANSMISSION HOUSING)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
Go to component -> Backup lamps circuit -> MULTI- INFROMATION DISPLAY UNIT
