Honda CR-V III facelift (2009-2012) Tire pressure monitoring circuit

+B TPMS BLK WIRE BLU WIRE CAN L CAN-H COMPUTER DATA LINES SYSTEM FAST CONTROLLER AREA NETWORK TRANSCEIVER FUSE 10 FUSE 20 GAUGE CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START JUNCTION K LINE LOW TIRE PRESSURE INDICATOR LT BLU WIRE MICU ORG/ WIRE POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER RED WIRE TPMS CONTROL UNIT (UNDER LEFT SIDE OF DASH) TPMS INDICATOR UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) VBU WARNING DRIVE CIRCUIT WHT WIRE YEL WIRE
