Honda CR-V III facelift (2009-2012) w/o automatic lighting system Wiring diagram
This page shows the only wiring diagram for the component.w/o automatic lighting system, which is found in the car Honda CR-V III facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o automatic lighting system (1 of 1)
+B TRAILER
B-CAN ODS
BACKUP LAMPS CIRCUIT
BACKUP LIGHT
BLK WIRE
BLU WIRE
BRN WIRE
FUSE
FUSE 10
FUSE 19
FUSE 27
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
IND CTRL (PTT)
L TURN LT
L TURN/STOP
LEFT FRONT TURN SIGNAL
LEFT TAILLIGHT
LICENSE PLATE LIGHT
LIGHT
LT GRN WIRE
MICU
ORG/ WIRE
P-GND
PCM (LEFT SIDE OF ENGINE COMPT)
PNK +B HAZ WIRE
PNK PNK WIRE
PNK WIRE
R TURN LT
R TURN STOP
REAR SIDE MARKER LIGHT
REAR TURN SIGNAL LIGHT
RED WIRE
RED YEL/ WIRE
RIGHT FRONT TURN SIGNAL HIGH MOUNT BRAKE LIGHT LIGHT
RIGHT TAILLIGHT
S GND
SMALL
SMALL (TRAILER)
SRS UNIT (UNDER MIDDLE OF DASH)
STOP SW
SW IN (BKSW)
TAILLIGHT RELAY
TAILLIGHT/BRAKE LIGHT
TRAILER HITCH CONNECTOR
TRAILER LIGHTING CONNECTOR
TRAILER LIGHTING CONTROL UNIT (ACCESSORY INSTALLED)
TRAILER LIGHTING IN-LINE FUSE
TURN SIGNAL/HAZARD FLASHER CIRCUIT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
W/ AUTOMATIC LIGHTING SYSTEM
W/O AUTOMATIC LIGHTING SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> W/O AUTOMATIC LIGHTING SYSTEM
