Instrument illumination circuit for Honda CR-V III (2006-2009)

AUDIO (UNDER MIDDLE UNIT OF DASH) BLK WIRE BLU WIRE COMBI GND (LIGHT) H/L OFF SW SMALL LT SW EX-L: W/ NAVIGATION FRONT PASSENGER'S SEAT HEATER SWITCH (EX-L) NAVIGATION UNIT FUSE 10 GLOVE BOX LIGHT GRN WIRE GRY WIRE H/L ON SW B-CAN ILLUM- HAZARD WARNING SWITCH/ PASSENGER'S AIR BAG CUTOFF INDICATOR HEAD HEAD OFF HEADLIGHT SWITCH COMBINATION LIGHT SWITCH HOT IN ON OR START LX, EX, EX-L W/O NAVIGATION MICU MOONROOF SWITCH (EX, EX-L) OFF ORG/ WIRE P-GND PARK PARK PIN SWITCH (UNDER MIDDLE OF DASH) PNK WIRE POWER MIRROR SWITCH RED WIRE S GND UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) VSA OFF SWITCH

+B SMALL AREA NETWORK TRANSCEIVER BODY CONTROLLER AUDIO REMOTE SWITCH BLK WIRE CABLE REEL (TOP OF STEERING COLUMN) CONTROLLER AREA NETWORK CONTROLLER POWER SUPPLY CIRCUIT/ CRUISE CONTROL SET/ RESUME CANCEL SWITCH DRIVER'S SEAT HEATER SWITCH (EX-L) ENGINE COMPT) FUSE 14 FUSE 19 FUSE 23 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEATER CONTROL PANEL HOT AT ALL TIMES ILLUMI (-) ILLUMINATION CONTROL FOR ILLUMINATION CONTROL FOR DIAL (WHITE) ILLUMINATION CONTROL FOR FT LCD (WHITE) ILLUMINATION CONTROL FOR LCD (AMBER) ILLUMINATION CONTROL FOR LCD (WHITE) JUNCTION CONNECTOR MICU ORG/ WIRE PNK WIRE POINTERS (RED) WIRE RED WIRE STABILIZE STEERING WHEEL) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (ON LEFT SIDE OF VBU VOICE CONTROL SWITCH (EX-L W/ NAVIGATION) VOLUME ILLUMINATION YEL WIRE
