Honda CR-V III (2006-2009) tailgate opener switch Wiring diagrams

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 PNK WIRE AUDIO UNIT BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) EX, EX-L W/O NAVIGATION SCTY RADIO EX-L: W/ NAVIGATION FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) FRONT PASSENGER'S WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOOD SWITCH (FRONT OF ENGINE COMPT) HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH (UNDER LEFT SIDE OF DASH) IGNITION SWITCH) PNK PNK PNK WIRE IMMOBILIZER CONTROL UNIT- RECEIVER INTERIOR LIGHTS SYSTEM DRIVER'S DOOR LOCK SWITCH LEFT REAR DOOR LOCK KNOB SWITCH LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LOCK LT BLU WIRE LT GRN WIRE NAVIGATION UNIT ORG/ WIRE PNK B-CAN WIRE PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER POWER WINDOW MASTER SWITCH/ DRIVER'S DOOR LOCK SWITCH PPL RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) SCTY RADIO SECURITY INDICATOR TAILGATE LATCH SWITCH (BOTTOM OF TAILGATE OPENER SWITCH TAILGATE) UNDER-DASH JUNCTION BOX UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE YEL/RED WIRE

BLK WIRE CARGO AREA ACCESSORY POWER SOCKET CONSOLE ACCESSORY POWER SOCKET DRIVER'S SEAT BELT BUCKLE SWITCH EX-L FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FUEL TANK UNIT HIGH MOUNT BRAKE LIGHT LEFT BACK-UP LIGHT LEFT REAR SIDE MARKER LIGHT LEFT BRAKE LIGHT/ TAILLIGHT LEFT REAR TURN SIGNAL LIGHT LEFT TAILLIGHT ASSEMBLY LICENSE PLATE LIGHT LX, EX MICU MICU SERVICE CHECK CONNECTOR ODS UNIT P-GND PASSENGER'S SEAT CUSHION HEATER PASSENGER'S SEAT HEATER HIGH TEMPERATURE RELAY PASSENGER'S SEAT HEATER LOW TEMPERATURE RELAY REAR WINDOW DEFOGGER REAR WINDOW WIPER MOTOR RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH S GND SEAT BACK CUSHION HEATER SEAT HEATER HIGH TEMPERATURE RELAY SEAT HEATER LOW TEMPERATURE RELAY TAILGATE LATCH SWITCH TAILGATE OPENER SOLENOID TAILGATE OPENER SWITCH TO GROUND YAW RATE-LATERAL ACCELERATION SENSOR YEL WIRE

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 PNK WIRE AUDIO UNIT BLK WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER DRIVER'S DOOR SWITCH (ON LEFT "B" PILLAR) EX, EX-L W/O NAVIGATION SCTY RADIO EX-L: W/ NAVIGATION FRONT PASSENGER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR SWITCH (ON RIGHT "B" PILLAR) FRONT PASSENGER'S WINDOW SWITCH FUSE 23 FUSE 12 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOOD SWITCH (FRONT OF ENGINE COMPT) HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH (UNDER LEFT SIDE OF DASH) IGNITION SWITCH) PNK PNK PNK WIRE IMMOBILIZER CONTROL UNIT- RECEIVER INTERIOR LIGHTS SYSTEM DRIVER'S DOOR LOCK SWITCH LEFT REAR DOOR LOCK KNOB SWITCH LEFT REAR DOOR SWITCH (IN LEFT "C" PILLAR) LOCK LT BLU WIRE LT GRN WIRE NAVIGATION UNIT ORG/ WIRE PNK B-CAN WIRE PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER POWER WINDOW MASTER SWITCH/ DRIVER'S DOOR LOCK SWITCH PPL RIGHT REAR DOOR SWITCH (IN RIGHT "C" PILLAR) SCTY RADIO SECURITY INDICATOR TAILGATE LATCH SWITCH (BOTTOM OF TAILGATE OPENER SWITCH TAILGATE) UNDER-DASH JUNCTION BOX UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) UNLOCK WHT WIRE YEL WIRE YEL/RED WIRE

+B SMALL GND BLK WIRE BLU WIRE FUSE 19 GRN WIRE HOT AT ALL TIMES PNK WIRE T/G HANDLE SW T/G UNLOCK TAILGATE LATCH SWITCH (BOTTOM OF TAILGATE) TAILGATE OPENER SOLENOID (BOTTOM OF TAILGATE) TAILGATE OPENER SWITCH UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) MICU T/G HANDLE SW WHT WIRE
