Car Wiring Diagrams for Shift interlock circuit for Honda CR-V II facelift (2004-2006)

ATP -N ATPN BLK WIRE BLK/RED WIRE BLU/RED WIRE BRAKE PEDAL POSITION SWITCH (BEHIND DASH, FUSE 10 FUSE 7 FUSE 8 GAUGE ASSEMBLY HOT AT ALL TIMES HOT IN ACC OR ON HOT IN ON OR START IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT JUNCTION CONNECTOR KEY INTERLOCK SOLENOID KEY LOCK SOL + KEY SW METER MULTIPLEX CONTROL UNIT P PIN SW P-PINSW PARK PIN SWITCH PCM (BEHIND RIGHT SIDE OF DASH) RADIO RED WIRE RED/BLK WIRE RED/WHT WIRE SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH) SHIFT LOCK SOLENOID STOP SW TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDER-HOOD FUSE/RELAY BOX (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE
