Horn circuit for Honda CR-V II facelift (2004-2006)
Horn circuit
BLU WIRE
BLU/RED WIRE
BOX (ON LEFT SIDE OF ENGINE COMPT)
BRN WIRE
CABLE REEL
CRUISE CONTROL SET/ RESUME CANCEL SWITCH
EXCEPT LX
FUSE 7
HIGH HORN (BEHIND LEFT SIDE OF FRONT BUMPER)
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
LOW HORN (BEHIND LEFT SIDE OF FRONT BUMPER)
MULTIPLEX CONTROL UNIT
NCA WIRE
ORG/ WIRE
RED WIRE
SECURITY CONTROL UNIT CONNECTOR (OPTIONAL) (BEHIND LEFT SIDE OF DASH)
STEERING WHEEL)
UNDERHOOD FUSE/RELAY
