Car Wiring Diagrams for Instrument illumination circuit for Honda CR-V II (2001-2004)

AUDIO UNIT BLK WIRE BLU WIRE COIN POCKET LIGHT COMBINATION LIGHT SWITCH CRUISE CONTROL MAIN SWITCH EX-L FUSE 2 GAUGE ASSEMBLY GLOVE BOX LIGHT GRN WIRE HAZARD WARNING SWITCH HEAD OFF PARK HEADLIGHT SWITCH HEATER CONTROL UNIT- PANEL HOT AT ALL TIMES INSTRUMENT CLUSTER SYSTEM LCD BACK LIGHT M/T MOONROOF SWITCH MULTIPLEX CONTROL UNIT ODO/TRIP LCD BACK LIGHT STABILIZING POWER CIRCUIT POWER MIRROR SWITCH RED WIRE RED/BLK WIRE SEAT HEATER SWITCH SECURITY CONTROL UNIT CONNECTOR (UNDER LEFT SIDE OF DASH) TAILLIGHT RELAY UNDERHOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE
