Honda CR-V I facelift (1999-2001) wiper switch on input Wiring diagram
This page shows the only wiring diagram for the component.wiper switch on input, which is found in the car Honda CR-V I facelift (1999-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper switch on input (1 of 1)
BLK WIRE
BLU WIRE
COMBINATION WIPER SWITCH
GRN WIRE
GRN/BLK WIRE
HOT IN ON OR START
INTEGRATED CONTROL UNIT
LT GRN WIRE
PARK
PARK INPUT
REAR WINDOW INTERMITTENT WIPER RELAY CIRCUIT
REAR WINDOW WASHER MOTOR (ON WASHER FLUID RESERVOIR)
REAR WINDOW WIPER MOTOR (BELOW MIDDLE OF REAR WINDOW)
REAR WINDOW WIPER/ WASHER SWITCH
RED WIRE
RR WIPER RR WASHER FUSE 3
RUN WIRE
UNDERDASH FUSE/RELAY BOX (BEHIND DASH, LEFT OF STEERING COLUMN)
WASH
WASH ON OFF
WASHER SWITCH ON INPUT
WHT WIRE
WIPER CTRL
WIPER SWITCH ON INPUT
Go to component -> Rear wiper/washer circuit -> WIPER SWITCH ON INPUT
