Honda CR-V I facelift (1999-2001) 7 6 8 15 select unlock lock input unlock input ign key input Wiring diagram

7 6 8 15 SELECT UNLOCK LOCK INPUT UNLOCK INPUT IGN KEY INPUT BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE CEILING LIGHT HORN RLY CNTL DRIVER'S DOOR LOCK ACTUATOR DRIVER'S DOOR LOCK SWITCH FRONT PASSENGER'S DOOR LOCK ACTUATOR FUSE 25 METER FUSE 51 DOOR LOCK UNIT, ROOF GRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE HORNS SYSTEM HOT AT ALL TIMES HOT IN ON OR START IGNITION INPUT GROUND UNLOCK OUTPUT IGNITION KEY SWITCH INTERIOR LIGHTS SYSTEM (DOOR SWITCHES) KEYLESS OR POWER DOOR LOCK CONTROL UNIT (IN DRIVER'S DOOR) LEFT REAR DOOR LOCK ACTUATOR LT GRN/RED WIRE RED WIRE RIGHT REAR DOOR LOCK ACTUATOR SECURITY CONTROL UNIT (W/ ANTI-THEFT) (BEHIND LEFT KICK PANEL) STEERING LOCK TRUNK,TAILGATE, FUEL DOORS SYSTEM (RELEASES) UNDERDASH FUSE/RELAY BOX (BEHIND DASH, LEFT OF STEERING COLUMN) UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT) W/ ANTI- THEFT W/0 ANTI- THEFT W/O ANTI- THEFT WARNING SYSTEM WHT WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE
